Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
Vehicle Takeover
Firmware notes
Remote Start: Wait 10 seconds after remote start shutdown before remote starting the vehicle again.
Š
Key2GO is mandatory to control the immobilizer override in this firmware.
Š
THGMN4 or THGMN5 : The optional Plug & Play t-Harnesses are sold separately
Š
Loose wires: All T-Harness wires not listed in the diagram are not required for the installation. Loose wires such as Siren Output
Š
and Hood Input may need to be pulled from the tapped section of the T-harness. Refer to the "wiring diagram with T-Harness" for
more information on connections and installation instructions.
All T-Harness wires not listed in the diagram are not required for the installation.
Š
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Š
Fuses positioning: It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed
Š
on each wiring diagram.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic connector.
Š
Refer to the "Vehicle connections" following the installation diagram.
Š
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Siren: The siren is only required when enabling the security features during module flashing.
[3] Security-Only: Refer to the "Locating components in the vehicle" section for optional starter disable connection information.
5
933.GM9 2.46.198.9 2022 Chevrolet Equinox (Smart Key)
©2023 Directed. All rights
THGMN4 or THGMN5
Refer to the Quick Reference Guide section for more details.
Keys required for 1 Keys required
programming for operation
