Vehicle connections

The connection information listed below is specific to the 2022 Chevrolet Equinox (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low
H1/2 Tan/Black (Data) HS CAN High
H1/3 Orange/Brown No Connection
H1/4 Orange/Green No Connection
H1/5 Lt. Green (Data) Single Wire CAN
H1/6 Violet/Brown
(MUX) Brake Activation Output
H1/7 Orange/Black No Connection
H1/8 Yellow/Black (Data) Immo. Data (conn. side)
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) Parking Light Output
H2/2 Blue/White
(-) Ground When Armed (GWA) Output
H2/3 Dk. Green/Black (-) Lock Output
H2/4 Red/White (-) Trunk Release Output
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) AUX 1 Output
H2/7 White (+) AUX 1 Output
H2/8 Violet/Black (+) AUX 2 Output
H2/9 Dk. Blue/Black (-) Unlock Output
H2/10 Lt. Blue/Black (-) Factory Alarm Disarrn Output
H2/11 Brown/Red
(+) Siren Output
H2/12 Pink (+) Ignition Sense Input
H2/13 Violet (+) Door Input
H2/14 Brown (+) Brake Input
H2/15 White/Blue (-) Activation Input
12 933.GM9 2.46.198.9 2022 Chevrolet Equinox (Smart Key)
©2023 Directed. All rights
Connects To
Wire Location
BCM in center console front passenger side, white 26 pin plug, pin 24
BCM in center console front passenger side, white 26 pin plug, pin 25
No Connection
No Connection
BCM in center console front passenger side, blue 27 pin plug, pin 22
[3] BCM in center console front passenger side, blue 27 pin plug, pin 7
Hook up brake for automatic transmission vehicles or clutch for manual
transmission vehicles, not both.
No Connection
BCM in center console front passenger side, green 25 pin plug, pin 2
Connects To
Wire Location
BCM in center console front passenger side, white 26 pin plug, pin 22
[4] Starter:
Starter Motor --or-- Underhood Fuse Box, gray 60 pin plug (X3), pin
34
Ignition:
BCM in center console front passenger side, green 25 pin plug, pin 6
Must use a relay.
Must use a 1N4002 diode or larger.
No Connection
No Connection
BCM in center console front passenger side, brown 26 pin plug, pin 19
No Connection
No Connection
No Connection
No Connection
No Connection
[2] The siren is only required when enabling the security features during
module flashing.
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
Data White Mandatory
Data Blue Mandatory
Data Green Mandatory
MUX Blue/Yellow Remote Start
Only
Data Green/Violet Remote Start
Only
(+/-) Wire Color Connection
- Green/Gray Mandatory
+ Yellow Security Only
+ Violet/Black
- Brown/White Optional
Security Only
