Polycom RSS 2000 Getting Started Manual page 3

Changing the Initial IP Address via an RS-232 Console or
Telnet
Another option to modify the IP address of the RSS 2000 is using the
RS232 console.
1. Connect to the RS232 port – and activate the console (9600,
8bits).
2. Login, using the default Login name: polycom (or any
administrator password).
When you are logged in to the console, you will see the system's
current IP address.
3. Change the default IP address to the site's IP address.
In the command line (#), enter:
set lan1 static <IP address> mask < IP address> [gw < IP
address>]
Note
• These steps are also applicable to Telnet connection.
•
You can use either Telnet or RS232, not both to configure
the initial system IP addresses.
The system is now ready for use. For additional configuration
information, refer to the RSS200 User's Guide.
DOC2153A RSS 2000 Getting Started guide - V1 0.doc
RSS 2000 Maximum Capacity
Scenario Description
Conference How many conferences
Recording can be recorded
simultaneously
Point to How many point to point
Point calls can be record (if
recording both are dialing into the
POLYCOM ™ RSS
2000)
H323 How many conferences
Playback can be playback in H323
Archive view How many streaming
can be reviewed
(unicast) – based on the
Web Server capacity
Network TCP/UDP Ports used by RSS 2000
Usage
Manager
Web
Trace
Gatekeeper
RAS
Endpoint/
Q.931 Socket
H.323
H.245 Socket
Audio / Video / Data
Live Broadcast
Media
On Demand Archive
Page 3
Maximum Capacity
2 conference or 2 EPs
dialing in the same time1
H239 recorded link at a
time
1
10
60
Type Port Range
TCP 81
TCP 80
UDP 30011
UDP 1719
UDP 1720
TCP 1720
TCP 1730-1739
UDP 2000-2099
TCP 1800-1801
TCP 2800-2859
