Instrument Operating Conditions
Altitude up to 4000 meters (only limited when plugged into the
AC/DC adapter)
Relative humidity up to 80% RH, non-condensing
Pollution Degree II
Overvoltage Category II
Data Storage Capabilities
Range: ............................ 162,200 samples and 200 TESTIDs
Logging Interval
Intervals: ......................... 1 second to 1 hour
Time Constant
Intervals: ......................... User selectable
External Meter Dimensions
3.2 in.  9.5 in.  1.6 in. (8.1 cm  24.1 cm  4.1 cm)
Meter Weight
Weight with Batteries: ..... 0.9 lbs (0.41kg)
Power Requirements
Four (4) AA-size batteries (included) or AC/DC power supply
P/N 6013125
Input: ...............................
Output: ............................
1
Temperature compensated over an air temperature range of 40 to 150°F
(5 to 65°C).
2
The accuracy statement of ±3.0% of reading or ±3 ft/min (±0.015 m/s), whichever is
greater, begins at 30 ft/min through 9999 ft/min (0.15 m/s through 50 m/s).
3
Pressure velocity measurements are not recommended below 1000 ft/min (5 m/s) and
are best suited to velocities over 2000 ft/min (10.00 m/s). Range can vary depending
on barometric pressure.
4
Accuracy is a function of converting pressure to velocity. Conversion accuracy
improves when actual pressure values increase.
5
Accuracy with instrument case at 77°F (25°C), add uncertainty of 0.05°F/°F
(0.03°C/°C) for change in instrument temperature.
6
Accuracy with probe at 77°F (25°C). Add uncertainty of 0.1% RH/°F (0.2% RH/°C) for
change in probe temperature. Includes 1% hysteresis.
7
Overpressure range = 190 in. H
8
At 77°F (25°C). Add uncertainty of ±0.2%/°F (0.36%/°C) for change in temperature.
9
At calibration temperature. Add uncertainty of ±0.28%/°F (0.5%/°C) for change
in temperature.
® ®
VelociCalc /VeloCalc Pro Air Velocity Meter 9600 Series
(one sample can contain multiple
measurement types)
100 to 240 VAC, 50 to 60 Hz, 1.0A
12 VDC, 3.0A
O (7 psi, 360 mmHg, 48 kPa).
