- Page 1 VELOCICALC ® AIR VELOCITY METER MODEL 9565 SERIES OPERATION AND SERVICE MANUAL P/N 6004851, REVISION F JUNE 2018 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 2 GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
- Page 3 Copyright TSI Incorporated / 2011-2018 / All rights reserved. Address TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA Fax No. (651) 490-3824 Limitation Of Warranty And Liability (effective February 2015) Seller warrants the goods, excluding software, sold hereunder, under normal use and service as described in the operator's manual, to be free from defects in workmanship and material for 24 months, or if less, the length of time specified in the operator's manual, from the date of shipment to the customer.
- Page 4 INJURIES, OR DAMAGES CONCERNING THE GOODS (INCLUDING CLAIMS BASED ON CONTRACT, NEGLIGENCE, TORT, STRICT LIABILITY OR OTHERWISE) SHALL BE THE RETURN OF GOODS TO SELLER AND THE REFUND OF THE PURCHASE PRICE, OR, AT THE OPTION OF SELLER, THE REPAIR OR REPLACEMENT OF THE GOODS. IN THE CASE OF SOFTWARE, SELLER WILL REPAIR OR REPLACE DEFECTIVE SOFTWARE OR IF UNABLE TO DO SO, WILL REFUND THE PURCHASE PRICE OF THE SOFTWARE.
-
Page 5: Table Of Contents
Using the Telescoping Thermoanemometer Probes ...... 7 Extending the Probe ..............7 Retracting the Probe ..............7 Using the Pressure Ports (9565-P) ..........8 Connecting the Static Pressure Probe ........8 Connecting an Optional Pitot Probe or Airflow (straight pitot) Probe ................9 Thermocouple Ports .............. - Page 6 ZERO CO ..................33 APPLICATIONS ................. 34 CALIBRATION .................. 35 BLUETOOTH FUNCTIONS (Models 9565-P and 9565-X only) ..... 35 Discover Devices ..............35 Discoverability ................36 PINcode ................... 36 # AutoConnects ............... 36 Printing Data Using the Portable Printer (Models 9565-P and 9565-X only) ................
-
Page 7: Chapter 1 Unpacking And Parts Identification
If anything is missing or damaged, notify TSI immediately. 1. Carrying case 2. Instrument 3. Static pressure tip (9565-P and 9565-P-NB models only) 4. Rubber tubing (9565-P and 9565-P-NB models only) 5. USB cable 6. TrakPro CD-ROM with data analysis software 7. - Page 8 NO T E This device may not cause interference; this device must accept any interference, including interference that may cause undesired operation of the device. l’appareil ne doit pas produire de brouillage; l’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
- Page 9 W A R N I N G Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 10: Chapter 2 Setting-Up
Chapter 2 Setting-up Supplying Power to the Model 9565 Series The Model 9565 VelociCalc Air Velocity Meter can be powered in ® one of two ways: four size AA batteries or the AC adapter. Installing the Batteries Insert four AA batteries as indicated by the diagram located on the inside of the battery compartment. -
Page 11: Using The Ac Adapter
DO NOT attempt to charge alkaline batteries. Using the AC Adapter The AC adapter can be used to power the instrument or to charge the NiMH batteries when the DIP switch in the battery compartment is set to NiMH. If the DIP switch is set to Alkaline, and the AC power adapter is connected, then the batteries will be bypassed and the meter will be powered by the AC adapter. -
Page 12: Connecting Ventilation Or Iaq Probes
Connecting Ventilation or IAQ Probes The ventilation and IAQ probes have a “D” shape overmolding on the mini-DIN connector which must align with the connector at the base of the 9565 series meter. This will ensure the probe is properly connected and remains so during use. -
Page 13: Using The Pressure Ports (9565-P)
Connecting the Static Pressure Probe The Static Pressure probe included with the 9565-P is connected to the + port on the 9565-P using the included tubing. The Static Pressure probe is used to measure the duct static pressure and features a magnet which holds the probe to the ductwork. -
Page 14: Connecting An Optional Pitot Probe Or Airflow (Straight Pitot) Probe
When connected to a pitot probe, air velocity or air volume can be measured. A pitot probe can be connected to the “+” and “-” pressure ports on the Model 9565-P using two pieces of tubing of equal length. The total pressure port of the pitot probe connects to the “+”... -
Page 15: Thermocouple Ports
DO NOT use the instrument or probes near hazardous voltage sources since serious injury could result. Thermocouple Ports The 9565 series includes two thermocouple ports at the base of the meter. Any K-Alloy thermocouple with mini-connector can be attached. See Display Setup for setting the thermocouple temperature readings to be displayed as TC1, TC2, or TC1-TC2. -
Page 16: Connecting The Optional Bluetooth Portable Printer Device (Models 9565-P And 9565-X Only)
Connecting the Optional Bluetooth ® Portable Printer Device (Models 9565-P and 9565-X only) To connect the Bluetooth printer to the Model 9565, power on the unit and the printer. Then press the MENU soft key. From the Menu use keys to highlight Bluetooth Functions and press the ... -
Page 17: Chapter 3 Operation
Chapter 3 Operation Keypad Functions ON/OFF ( ) Key Press the ON/OFF key to turn the Model 9565 on and off. During the power up sequence the display will show the following: Model Number, Serial Number, and Software Revision. To turn the instrument off, press and hold the ON/OFF Key for 3 seconds. -
Page 18: Common Terms
Arrow (or ) and Press arrow keys to change choices while setting a Menu Soft Keys parameter. Press the Menu soft key to select the Menu selections, which are Pressure Zero, Display Setup, Settings, Flow Setup, VOC Setup, Actual/Std Setup, Data Logging, Zero CO, Applications, Calibration, and Bluetooth Functions. -
Page 19: Menus
Menus The menu structure is organized to allow easy navigation and instrument setup utilizing the arrow keys and button. To exit a menu or menu item, press the ESC key. To access the Menu items, press the Menu soft key. ... -
Page 20: Display Setup
DISPLAY SETUP Display Setup menu is where you will setup the desired parameters to be displayed on the instrument screen. With a parameter highlighted you can then use the ON soft key to have it show up on the instrument screen or select the OFF soft key to turn off the parameter. -
Page 21: Settings
SETTINGS Settings menu is where you can set the general settings. These include Language, Beeper, Select Units, Time Constant, Contrast, Set Time, Set Date, Time Format, Date Format, Number Format, Backlight and Auto Off. Use the or keys to select an option, and ... - Page 22 Round duct, Rect duct and Duct area are used to perform a duct traverse using a pitot probe or thermoanemometer probe. For more information on how to perform a duct traverse, refer to Application Note TSI-106. Press/Kfact allows for calculating flow rate from diffusers or flow stations with pressure taps using the instruments pressure ports and Kfactors.
-
Page 23: Voc Setup
When measuring Flow as the Primary measurement, the parameters can be quickly changed by pressing the or key while on the main measurement screen: Make adjustments with the or arrow keys and press accept, or enter the Select Duct or Select Kfactor menu to choose a different pre-programmed flow value or dimension. -
Page 24: Actual/Standard Setup
ACTUAL/STANDARD SETUP Choose Actual/Standard measurements and parameters in the Act/Std Setup menu. The Model 9565 measures the actual barometric pressure using an internal sensor. The temperature source can be entered manually or taken from a probe that measures temperature (plug in probe or thermocouple). The Entered Temp range is from -40 to 1832°F (-40 to 1000°C). -
Page 25: Data Logging
DATA LOGGING Measurements Measurements to be logged to memory are independent of measurements on the display, and must therefore be selected under DATA LOGGING Measurements. When set to ON, measurement will be logged to memory. When set to DISPLAY, measurement will be logged to memory if it is visible on the main running screen. - Page 26 Manual Logging Manual mode does not automatically save data, but instead prompts the user to SAVE a sample or ESC to not save. To start logging, press the key. N O T E To adjust the averaging period for a sample when using Manual logging, change the Time Constant (increase or decrease in seconds) which is located in the Settings Menu.
- Page 27 When set to Auto-save, the Sample Time can be adjusted. Sample Time is the time period over which the Sample will be averaged. DATA LOGGING SAMPLE TIME Measurements Log Mode Auto-save Log Settings 00:05 Choose Test Test 001 Min:Sec Name Test View Data Delete Data % Memory...
- Page 28 When set to Cont. key, the log interval can be adjusted. DATA LOGGING LOG SETTINGS Measurements LOG INTERVAL Log Mode Cont.-key Log Interval 00:01 Log Settings 00:05 Min:Sec Choose Test Test 001 Name Test View Data Delete Data % Memory N O T E Pressing the ...
- Page 29 When set to Cont.-time, the log interval and test length can be adjusted. DATA LOGGING LOG SETTINGS Measurements LOG INTERVAL Log Mode Cont.-time Log Interval 00:01 Log Settings 00:05 Test Length 00:00:01 Min:Sec Choose Test Test 001 Name Test View Data TEST LENGTH Delete Data % Memory...
- Page 30 Program 1 and Program 2 Program 1 and Program 2 are customized data logging setup programs. Setting them up is performed using TSI’s TrakPro ™ Data Analysis software. DATA LOGGING LOG MODE Measurements Log Mode Cont.-time Manual Log Settings Auto-save Choose Test Test 001 Cont.-key...
-
Page 31: Choose Test
Choose Test Test IDs consist of a group of Samples that are used to determine statistics (average, minimum, and maximum) of a measurement application. The 9565 can store 26,500+ samples and 100 test IDs (one sample can contain fourteen measurement types). Example: Each duct traverse will have its own Test ID consisting of several Samples. -
Page 32: View Data
View Data Choose Test To view stored data, first select the Test ID that contains the data to be recalled. This is accomplished in the “Choose Test” menu. DATA LOGGING Measurements VIEW DATA CHOOSE TEST Log Mode Auto-save Choose Test Test 001 View Stats Test 001... -
Page 33: View Stats
Use the < or > keys to view statistics of each measurement parameter. The 9565-P and 9565-X can send this data to the optional Model 8934 wireless printer or PC capable of Bluetooth communications. To use the PRINT command, Bluetooth... -
Page 34: Print Test
13.5%rh PRINT PRINT PRINT The 9565-P and 9565-X can send this data to the optional Model 8934 wireless printer or PC capable of Bluetooth communications. To use the PRINT command, Bluetooth communications must be established between the instrument and the Model 8934 wireless printer or PC set up with Bluetooth communications. -
Page 35: Delete Data
Delete Data Use this to delete all data, delete test or delete sample. DATA LOGGING DELETE DATA Measurements Delete All Log Mode Cont.-time Log Settings Delete Test Choose Test Test 001 Delete Sample Name Test View Data Delete Data % Memory Delete All will clear stored data in all Test IDs. -
Page 36: Memory
Delete Sample will clear the last sample in an individual Test ID selected by the user. DELETE DATA DELETE SAMPLE Delete All Test 001 14 Samples Delete Test Test 002 10 Samples Delete Sample Test 003 12 Samples Test 004 8 Samples Test 005 7 Samples... -
Page 37: Zero Co
ZERO CO This menu item applies to TSI probe Model 982 which can measure carbon monoxide (CO). Turn the instrument on for a minimum of five minutes to let it warm up before zeroing the CO sensor. Zero CO will zero the CO sensor readings that may have drifted. -
Page 38: Applications
APPLICATIONS This menu option includes specialized measurement protocols used to perform various tests or investigations. You can choose Draft Rate, Heat flow, Turbulence, % Outside Air, and Leakage Test in the Applications menu. For more information on these applications, refer to the following information: ... -
Page 39: Calibration
Restore Factory Cal Calibration Bluetooth Functions BLUETOOTH FUNCTIONS (Models 9565-P and 9565-X only) VelociCalc Models 9565-P and 9565-X contains a Bluetooth Functions menu which is used to adjust parameters to assist with wireless connections to other Bluetooth capable devices. MENU... -
Page 40: Discoverability
For more information on establishing Bluetooth connections, refer to Applications Note TSI-150. Printing Data Using the Portable Printer (Models 9565-P and 9565-X only) To print logged data, first enter the DATALOGGING menu. Then, use the CHOOSE TEST item to select the data to be printed. After the test is selected, use the VIEW STATS and VIEW SAMPLES items to select statistics or individual data points to view and print. -
Page 41: Trakpro™ Data Analysis Software
TrakPro™ Data Analysis Software The VelociCalc Model 9565 comes with special software called TrakPro Data Analysis Software, which is designed to provide you ™ with maximum flexibility and power. To download data from the Model 9565, connect the supplied computer interface USB cable to the Model 9565 and to a computer USB port. -
Page 42: Chapter 4 Maintenance
Chapter 4 Maintenance The Model 9565 and probe accessories require very little maintenance to keep it performing well. The Model 9565 and accessory probes can also be recalibrated in the field using the CALIBRATION menu. These field adjustments are intended to make minor changes in calibration to match a user's calibration standards. -
Page 43: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting Table 5-1 lists the symptoms, possible causes, and recommended solutions for common problems encountered with the Model 9565. If your symptom is not listed, or if none of the solutions solves your problem, please contact TSI. Table 5-1: Troubleshooting the Model 9565 Symptom Possible Causes Corrective Action... -
Page 44: Appendix A Specifications
Appendix A Specifications Specifications are subject to change without notice. Velocity (TA Probe): Range: 0 to 9999 ft/min (0 to 50 m/s) Accuracy ±3% of reading or ±3 ft/min (±0.015 m/s), whichever 1&2 is greater Resolution: 1 ft/min (0.01 m/s) Velocity (Pitot Tube): Range 250 to 15500 ft/min (1.27 to 78.7 m/s) - Page 45 Static / Differential Pressure: Range -15 to +15 in. H O (-28.0 to +28.0 mm Hg, -3735 to +3735 Pa) Accuracy: ±1% of reading ±0.005 in. H O (±1 Pa, ±0.01 mm Hg) Resolution: 0.001 in. H O (0.1 Pa, 0.01 mm Hg) Barometric Pressure: Range: 20.36 to 36.648 in.
-
Page 46: Power Requirements
Power Requirements: Four AA-size batteries (included) or AC Adapter p/n 801761 Input: 90 to 240 VAC, 50 to 60 Hz Output: 9 VDC, 2A Temperature compensated over an air temperature range of 40 to 150°F (5 to 65°C). The accuracy statement of ±3.0% of reading or ±3 ft/min (±0.015 m/s), whichever is greater, begins at 30 ft/min through 9999 ft/min (0.15 m/s through 50 m/s). -
Page 47: Appendix B Optional Plug-In Probes
Appendix B Optional Plug-in Probes Thermoanemometer Probes Model Description Air Velocity and Temperature, Straight Probe Air Velocity and Temperature, Articulating Probe Air Velocity, Temperature, and Humidity, Straight Probe Air Velocity, Temperature, and Humidity, Articulating Probe Rotating Vane Anemometer Probes Model Description 4 in. - Page 48 Pitot Probes Model Description 634634000 Pitot Probe 12" (30 cm) - 5/16" (8 mm) diameter 634634001 Pitot Probe 18" (46 cm) - 5/16" (8 mm) diameter 634634002 Pitot Probe 24" (61 cm) - 5/16" (8 mm) diameter 634634003 Pitot Probe 36" (91 cm) - 5/16" (8 mm) diameter 634634005 Pitot Probe 60"...
