TSI Instruments VelociCalc 9555 Quick Tips

TSI VelociCalc 9555/9565 Quick Tips for Pressure Testing
For complete documentation, see

1. Probe Sampling

a. Connect probe to bottom of instrument, and turn
the instrument on
b. To change the readings displayed on screen...
1. Select [Menu] softkey
2. Select Display Setup
3. Use the softkeys to select display values
(Primary sets value to a larger font to make it
more visible to the user)
a. 964 probe – Flow, Temperature, and %rH set to ON
b. 982 Probe – CO, CO2, Temperature and %rh set to ON
c. 985 Probe – VOC and Temperature set to ON
d. 995 Probe – Flow and Temperature set to ON
4. Press [Enter] to save changes.
c. Set up data logging values
1. Select [Menu] softkey
2. Select Data Logging
3. Select Measurements
4. Select values to be logged by instrument
a. ON = Measurement is logged to memory
b. Display = Measurement will be logged if it is displayed on the main screen
c. OFF = Unit will not save data for that value
d. Hold probe to take samples
e. [NEXT TEST] key saves data up to the point it is pressed and begins a new session
