T h e r m o c o u p l e P o r t
DO NOT use the instrument or probes near hazardous voltage
sources since serious injury could result.
The 9600 Series VelociCalc
thermocouple port at the base of the meter. Any K-alloy thermocouple
with mini-connector can be attached. See
for displaying the thermocouple measurement.

Connecting the Thermocouples

The K-alloy thermocouple with mini-connector has one terminal wider
than the other. The wider terminal will be inserted into the bottom of
the TC connector port.
TC
Operation and Service Manual
W A R N I N G
®
Air Velocity Meter includes a
Chapter 4, Display Order
K-alloy Thermocouple
