Summary of Contents for TSI Instruments VELOCICALC 9515
- Page 1 VELOCICALC ® AIR VELOCITY METER MODEL 9515 OPERATION AND SERVICE MANUAL P/N 1980555, REVISION D SEPTEMBER 2013...
- Page 3 Copyright TSI Incorporated / 2007–2013 / All rights reserved. Address TSI Incorporated / 500 Cardigan Road / Shoreview, MN 55126 / USA Fax No. (651) 490-3824 LIMITATION OF WARRANTY AND LIABILITY (effective June 2011) (For country-specific terms and conditions outside of the USA, please visit www.tsi.com.) Seller warrants the goods sold hereunder, under normal use and service as described in the operator's manual, shall be free from defects in workmanship and material for 24 months, or if less, the length of time specified in the operator's manual, from the date of...
- Page 4 Buyer and all users are deemed to have accepted this LIMITATION OF WARRANTY AND LIABILITY, which contains the complete and exclusive limited warranty of Seller. This LIMITATION OF WARRANTY AND LIABILITY may not be amended, modified or its terms waived, except by writing signed by an Officer of Seller. Service Policy Knowing that inoperative or defective instruments are as detrimental to TSI as they are to our customers, our service policy is designed to give prompt attention to any...
-
Page 5: Table Of Contents
CONTENTS CHAPTER 1 UNPACKING AND PARTS IDENTIFICATION .... 1 CHAPTER 2 SETTING-UP ..............3 Supplying Power to the Model 9515 V Air Velocity ELOCI Meter ....................3 Installing the Batteries ............... 3 Using The Telescoping Probe ............3 Extending The Probe ..............3 Retracting The Probe .............. - Page 6 (This page intentionally left blank)
-
Page 7: Chapter 1 Unpacking And Parts Identification
Chapter 1 Unpacking and Parts Identification Carefully unpack the instrument and accessories from the shipping container. Check the individual parts against the list of components below. If anything is missing or damaged, notify TSI immediately. 1. Carrying case 2. Instrument... - Page 8 (This page intentionally left blank) Chapter 1...
-
Page 9: Chapter 2 Setting-Up
Chapter 2 Setting-up Supplying Power to the Model 9515 V Air Velocity ELOCI Meter The Model 9515 is powered with four size AA batteries. Installing the Batteries Insert four AA batteries as indicated by the diagram located on the inside of the battery compartment. The Model 9515 is designed to operate with either alkaline or NiMH rechargeable batteries, although it will not recharge NiMH batteries. - Page 10 (This page intentionally left blank) Chapter 2...
-
Page 11: Chapter 3 Operation
Chapter 3 Operation Keypad Functions ON/OFF Key Press to turn the Model 9515 on and off. During the power up sequence the display will show the following: Model Number, Serial Number, Software Revision, and Last Date Calibrated. ft/min / m/s Key Pressing this key changes the display to read air velocity. - Page 12 (This page intentionally left blank) Chapter 3...
-
Page 13: Chapter 4 Maintenance
Chapter 4 Maintenance The Model 9515 requires very little maintenance to keep it performing well. Recalibration To maintain a high degree of accuracy in your measurements, we recommend that you return your Model 9515 to TSI for annual recalibration. Please contact one of TSI’s offices or your local distributor to make service arrangements and to receive a Return Material Authorization (RMA) number. - Page 14 (This page intentionally left blank) Chapter 4...
-
Page 15: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting Table 5-1 lists the symptoms, possible causes, and recommended solutions for common problems encountered with the Model 9515. If your symptom is not listed, or if none of the solutions solves your problem, please contact TSI. Table 5-1: Troubleshooting the V Model 9515 ELOCI Symptom... - Page 16 (This page intentionally left blank) Chapter 5...
-
Page 17: Appendix A Specifications
Appendix A Specifications Specifications are subject to change without notice. Velocity: Range: 0 to 4000 ft/min (0 to 20 m/s) 1&2 Accuracy ±5% of reading or ±5 ft/min (±0.025 m/s), whichever is greater Resolution: 1 ft/min (0.01 m/s) Temperature: Range: 0 to 200°F (-18 to 93°C) Accuracy ±0.5°F (±0.3°C) - Page 18 (This page intentionally left blank) Appendix A...
- Page 19 TSI Incorporated – Visit our website www.tsi.com for more information. Tel: +1 800 874 2811 India Tel: +91 80 67877200 Tel: +44 149 4 459200 China Tel: +86 10 8219 7688 France Tel: +33 4 91 11 87 64 Singapore Tel: +65 6595 6388 Germany Tel: +49 241 523030 P/N 1980555 Rev D ©2013 TSI Incorporated...
