- Page 1 INSTRUCTION MANUAL AIR 68 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x40mm SCREW M3.5x45mm SCREW 16PCS+1spare 8PCS+1spare M3.0x16mm SCREW M3.5x25mm SCREW 4PCS+1spare 16PCS+1spare Chewing toy M3.0x10mm SCREW 2PCS+1spare Connecting Piece M3.0x16mm SCREW 4PCS 12PCS+1spare... - Page 4 PARTS Side Panel Front Panel-Right Side Back Panel-Right Side 2PCS House Divider Run Divider Support Bar 2PCS 2PCS Tray Wire Floor Wooden Floor 2PCS 2PCS 2PCS...
- Page 5 PARTS Pen Cover Folding metal feeder Roof 4PCS 2PCS Front Panel-Left Side Roof Cap Back Panel- Left Side 2PCS Caster Without Brake Caster With Brake 3PCS 3PCS...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Screw Part A, B, C,D together by 4XP1 & 4XP2 screws. Use the connecting piece P7 to attached Part E by 4XP8 each side. - Page 7 PRODUCT ASSEMBLY Screw in the casters Part P & Q to the legs. ① Slide in the plastic tray Part G. ② Put the support bar Part F into the pen.
- Page 8 PRODUCT ASSEMBLY Put in the floor Part H & I. Attach metal feeder Part J by 2XP5 screw, then put in the chewing toy.
- Page 9 PRODUCT ASSEMBLY Attach the pen roof Part L by 4XP2 screws. Attach the roof Part by 4XP4 screw each side.
- Page 10 PRODUCT ASSEMBLY Attach the roof cap Part M by 2XP3 screws. ① Screw Part N, O, B, D together by 4XP1 & 4XP2 screws. ② Screw in the casters Part P & Q to the legs ③ Repeat the same assembly ways of Step 2 to Step 9.
- Page 11 PRODUCT ASSEMBLY Connect two hutches together by 2XP8 each side. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
