- Page 1 INSTRUCTION MANUAL AIR 74 AIR 73 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M6.0x30mm SCREW M3.0x18mm SCREW 8PCS+1spare 9CS+1spare M3.0x14mm SCREW M3.0x12mm SCREW 6CS+1spare 4PCS+1spare Hinge Lock... - Page 4 PARTS Back panel Right side panel Left side panel Bottom floor Back metal bar-left Back metal bar-right 2PCS Front metal bar-left Front panel PVC curtain...
- Page 5 PARTS Front metal bar-right Plastic Feet Roof 4PCS...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the plastic feet Part K to the metal bars Part D & E with the buckle. Attach the panel Part A, B, C, screw the metal bars Part D & E by 4XP1. - Page 7 PRODUCT ASSEMBLY Attach the plastic feet Part K to the metal bars Part I & J with the buckle. Screw the curtain Part G to the INSIDE of Part H by 3xP2.
- Page 8 PRODUCT ASSEMBLY Attach the Part H to the house, screw the metal bars Part I & J by 4XP1. Put down the left bottom floor first, then put down the right bottom floor.
- Page 9 PRODUCT ASSEMBLY Screw the roof Part L on asphalt part from bottom by 6xP2. Notice: The roof edges of back are relatively flat, pls pay attention the position. Screw the roof hinge P5, one side to the roof by 2xP3, the other side to the left side panel by 2xP3.
- Page 10 PRODUCT ASSEMBLY Screw the lock P6, screw one side to the roof by 2xP3, screw the other to the front panel by 4xP4.
- Page 11 PRODUCT ASSEMBLY Complete.
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
