- Page 1 NSTRUCTION MANUAL AIR 60 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 60MIN. ASSEMBLY HARDWARE M3.5x60 mm SCREW M3.5x35 mm SCREW 4PCS+1 spare 8PCS+1 spare M3.0x16 mm SCREW M4.0x40 mm BOLT 4PCS+1 spare 8PCS+1 spare Latch... - Page 4 PARTS Right pen panel Bottom plate Left pen panel (close to the hutch) (close to the hutch) Left pen panel Right pen panel Side panel of pen (outside) (outside) Roof of pen 2PCS...
-
Page 5: Product Assembly
PRODUCT ASSEMBLY Attach Part O& P to Part N by 4xP8 screws. Attach Part Q& R by 4xP2 screws. - Page 6 PRODUCT ASSEMBLY Attach front panel Part S by 4xP8 screws. Attach pen roof 2xPart T by 8xP4 screws.
- Page 7 PRODUCT ASSEMBLY Attach the lock P9 by 4XP6.
- Page 8 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this...
