- Page 1 INSTRUCTION MANUAL AIR42 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWERE M3.5x60mm SCREW M6.0x50mm Bolt 6PCS+ +1 spare 4PCS+1pare M3.5x35mm SCREW M4.0x45mm SCREW 8PCS ++ 1 spare 16PCS ++ 1 spare M3.5x25mm SCREW M3.5x20mm SCREW 20PCS ++ 1 spare 16PCS ++ 1 spare... - Page 4 PARTS Back panel-Upper Front panel-Upper Front panel-Down 1 PC 1 PC 1 PC Back panel-Down Left panel-Down Right & Left panel-Upper 1 PC 2 PCS 1 PC Right panel-Down Bottom wire netting Tray 1 PC 2PCS 1 PC...
- Page 5 PARTS Ramp Standing bar Front panel of small house 2 PCS 1 PC 1 PC Right & Left panel of Back panel of small Bottom panel of small small house house house 2PCS 1 PC 1 PC Roof Top panel of small Roof cap house 2 PCS...
- Page 6 PARTS Casters without Casters with brakes Wooden feeder 2 PCS 2 PCS 1 PC...
-
Page 7: Product Assembly
PRODUCT ASSEMBLY Attach the small house!Attach the part P,L ,2x N by 6X P6 screws. Attach the back panel of small house part M by 6XP6 screws. ... - Page 8 PRODUCT ASSEMBLY Attach the Bottom panel of small house part O by 4XP6 screws. Attach the hutch!Attach the Back panel-Down part D,to the side parts F & G by 4X P3 screws.
- Page 9 PRODUCT ASSEMBLY Attach the Wooden feeder part U by 2XP1 screws. Attach the Front panel-Down part B by 4X P3 screws. ...
- Page 10 PRODUCT ASSEMBLY Slide in the tray part I. Put the bottom wire netting 2pcs of part H inside the cage as show on the picture. ...
- Page 11 PRODUCT ASSEMBLY Put the ramp part J into the cage as show on the picture. Put the one of standing bar par K into the wire(in any place you want)
- Page 12 PRODUCT ASSEMBLY Attach the Back panel- U pper part C by 2X P2 screws. Attach the small house to the upper left corner of back panel Part C by 2X P1 screws.
- Page 13 PRODUCT ASSEMBLY Attach the Right & Left panel-Upper part E to back panel by 4 X P3 screws.Down to the side panels by 2 X P2 screws. ①Attach the Front panel-Upper part A to side panels by 4 X P3 screws,Down to the Front panel-Down by 2 X P2 screw.
- Page 14 PRODUCT ASSEMBLY Attact the roof Part Q to the hutch by 8 X P4 screws Attach the roof cap Part R by 4X P5 screws.
- Page 15 PRODUCT ASSEMBLY Screw 2pcs of Casters with brakes part S to the back 2 legs by 8 X P5 screws. Screw 2pcs of Casters without brakes part T to the front 2 legs by 8 X P5 screws. Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
