- Page 1 INSTRUCTION MANUAL AIR 62 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x25mm SCREW M3.5x40mm SCREW 28PCS+1 spare 16PCS+1 spare M3.0x16mm SCREW Lock 12PCS+1spare 2PCS Bowl Chewing toy Connector 2PCS （Only for 2 cages combination. not available for one cage owner) - Page 4 PARTS Panel of hideout Panel of hideout Panel of hideout 2PCS Roof of hideout Front panel-up Back panel Front panel-down Left panel Right panel...
- Page 5 PARTS Casters with brake Casters without brake Layer 2PCS 2PCS Ramp Tray Small layer Roof...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the hideout Part A, Part BX2, Part C, Part D by 12xP2. Attach the front Part F, G & back Part E to left Part H & right Part I by P1X12. X 12... - Page 7 PRODUCT ASSEMBLY Screw the caster Part J to the back of cage by 4XP2 each side. ① Screw the caster Part K to the front of cage by 4XP2 each side. ② Put layer Part L in lower position of the cage.
- Page 8 PRODUCT ASSEMBLY Slide in the tray Part M. ① Put the small layer Part N into the cage, hang the ramp Part O on ② Part N. Put the bowl Part P5, chewing toy Part P6 and the hideout into the cage.
- Page 9 PRODUCT ASSEMBLY Screw the roof Part P by 4XP1. Screw the lock Part P4X1 by P3X4 each side.
- Page 10 Notice Read Before Assemble! For 2 cages combination. ①Take out the right middle panel from cage 1. ②Take out the left middle panel from cage 2. CAGE 1 CAGE 2 Put the hideout, the small layer Part N, the ramp Part O into the cage. CAGE 1 CAGE 2...
- Page 11 PRODUCT ASSEMBLY Screw the Connector 2xP7 to the middle frame of the 2 cages by 4xP3 each side.
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
