- Page 1 NSTRUCTION MANUAL AIR 59 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 60MIN. ASSEMBLY HARDWARE M6.0x55 mm BOLT M3.5x60 mm SCREW 8PCS+1 spare 20PCS+1 spare M3.5x40 mm SCREW M3.5x35 mm SCREW 16PCS+1 spare 12PCS+1 spare M3.5x25 mm SCREW M3.0x16 mm SCREW 8PCS+1 spare 6PCS+1 spare Lock M3.0x12 mm SCREW... - Page 5 PARTS Upper panel-front and back Side panel Tray 2PCS 2PCS Side panel of nesting box Side panel of nesting box Perch 2PCS 2PCS 3PCS Front panel of nesting box Bottom of nesting box Divider 2PCS 2PCS 2PCS...
- Page 6 PARTS Roof of nesting box PVC Waterproof Strip Roof 2PCS 2PCS 2PCS Down panel- front and back Roof cap 2PCS 2PCS...
-
Page 7: Product Assembly
PRODUCT ASSEMBLY Attach Part A & N to the side panel Part B by 16XP2 screws, then connect the Part A & N by 2XP8 screws. - Page 8 PRODUCT ASSEMBLY Slide in the metal tray Part C. Insert the perches 3xPart D into the slots inside the front and back panel of coop.
- Page 9 PRODUCT ASSEMBLY Attach the side panels of nesting box Part E & F to the left side of coop by bolt 4xP1. Attach the side panels of nesting box Part E & F to the right side of coop by bolt 4xP1.
- Page 10 PRODUCT ASSEMBLY Attached the front panel of nesting box Part G by 4xP3 screws each side. . ① Drop in the bottom panel of nesting box Part H. ② Slide in the divider Part I each side.
- Page 11 PRODUCT ASSEMBLY ① Attach the roof of nesting box 2xPart J to the nesting box by 4XP5 screws each side. ② Make sure the lock is functioning properly before locking the roof. Attach the coop roof 2xPart K to the coop by 8XP3 screws.
- Page 12 PRODUCT ASSEMBLY Attach PVC Waterproof Strip 2xPart L to the nesting box by 4XP4 screws each side.
- Page 13 PRODUCT ASSEMBLY ① Attach the roof cap Part M by 4XP4 screws. ② Attach lock P7 to the tray by 6xP6. Finish here for only buying one coop...
- Page 14 Notice Read Before Assemble! Pls ignore the following for only one coop owner !
- Page 15 PRODUCT ASSEMBLY Attach the run to the coop by 2xP2 screws. Attach the run to the coop by 2xP2 screws. Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this...
