- Page 1 INSTRUCTION MANUAL AIR 65 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x45mm SCREW M3.5x60mm SCREW 10PCS+1spare 24PCS+1spare M3.5x25mm SCREW M3.5x35mm SCREW 4PCS+1spare 8PCS+1spare M3.5x40mm SCREW M3.0x16mm SCREW 8PCS+1spare 12PCS+1spare Lock 2PCS... - Page 4 PARTS Back Panel Front Panel- Upper Front Panel- Down Left Side Panel Tray-Upper Right Side Panel Ramp Support Wire Pen Tray-Down 3PCS...
- Page 5 PARTS Side Wire Pen Ramp Wire Pen-Right Back 1 PC 2PCS Roof of Pen Tray of Pen Roof of Hutch 2PCS 2PCS 2PCS Front casters without Back casters with brakes Back Panel-Down Roof Cap brakes 4PCS 4PCS...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the panel part A,B,C,D,E,S by 16XP2 screws. X 16 Attach the casters without brakes 2Xpart R in front and the casters with brakes 2Xpart Q in back. - Page 7 PRODUCT ASSEMBLY ① Slide in the tray part F & G. ② Attach the wire pen part H to the left side of hutch by 4XP1 screws. ① Attach the wire pen part H & J to the right side of hutch by 4XP1 screws.(Please pay attention the position of part J) ② Attach the ramp support part I to the part J by 2XP1 screws.
- Page 8 PRODUCT ASSEMBLY Screw the ramp part K to the right side panel by 4XP5 screws. Attach the 2Xpart R to the front of part L. Attach the 2Xpart Q to the back of part L.
- Page 9 PRODUCT ASSEMBLY Attach the side wire pen part L by 4XP2 screws each side. Attach the roof of pen part M by 4XP6 screws each side.
- Page 10 PRODUCT ASSEMBLY Slide in the tray part N. Attach the roof of hutch part O by 8XP3 screws.
- Page 11 PRODUCT ASSEMBLY Attach the roof cap part P by 4XP4 screws. Attach top panel of pen and side panel with 1XP7 by 4XP5 each side. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
