- Page 1 INSTRUCTION MANUAL AIR 43 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M3.5x35mm SCREW M4.0x60mm SCREW 12PCS+1spare 3PCS+1spare M3.0x16mm SCREW M3.5x25mm SCREW 11PCS+1spare 20PCS+1spare Hinge Plastic Feet 4PCS 2PCS... - Page 5 PARTS Back panel Front panel PVC curtain Left side bottom floor Left side panel Right side panel Divider panel Right side bottom floor Roof...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Screw the curtain Part B to the INSIDE of Part A by 3xP3 screws. Screw Part I to the INSIDE of Part A by 2xP2 screw. - Page 7 PRODUCT ASSEMBLY Pls line up the Part D & Part E as shown on the picture before attach the Part C to Part E & D by 6xP1. Side Panel (Part D & Part E) Back Panel (Part C) Put in bottom floor Part F and G.
- Page 8 PRODUCT ASSEMBLY ① Pls line up the Part D & Part E as shown on the picture before attach the Part A to Part E & D by 6xP1. Screw the divider panel to the bottom panel by 1xP2 screw. ② Side Panel (Part D &...
- Page 9 PRODUCT ASSEMBLY ① Screw the roof hinge to the back by 4xP2 screws on each one. ② Notice to level up before screwing together. ① Screw the roof hinge P5, one side to the roof by 2xP4 screws, the other side to the left side panel by 2xP4 screws. ② Repeat on the other side.
- Page 10 PRODUCT ASSEMBLY Attach 4pcs of P6 plastic feet.
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
