- Page 1 NSTRUCTION MANUAL AIR 67 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 60MIN. ASSEMBLY HARDWARE M6.0x55 mm BOLT M3.5x60 mm SCREW 8PCS+1 spare 20PCS+1 spare M3.5x40 mm SCREW M3.5x35 mm SCREW 12PCS+1 spare 8PCS+1 spare M3.5x25 mm SCREW M3.0x16 mm SCREW 24PCS+1 spare 14PCS+1 spare Lock Spacer... - Page 4 HARDWARE Connect pieces 2PCS...
- Page 5 PARTS Down panel- Back side Side Panel Upper panel-front and back Down panel- Front side 2PCS 2PCS Casters without brake Casters with brake Tray Perch 2PCS 2PCS 3PCS Left panel of nesting box Bottom panel of nesting box Right panel of nesting box Front panel of nesting box 2PCS 2PCS...
- Page 6 PARTS Roof Roof cap Divider Roof of nesting box 2PCS 2PCS 2PCS Bottom plate PVC Waterproof Strip Ramp 2PCS (Only need for connecting with the coop AIR60)
-
Page 7: Product Assembly
PRODUCT ASSEMBLY Attach Part A,B,C to the side panel Part D by P2x16; then connect the Part A to B&C by P2x2. - Page 8 PRODUCT ASSEMBLY ① Screw two casters without brake Part E to the front of coop legs by P5x6 using the P8 spacer. ② Screw two casters with brake Part F to the back of coop legs by P5x6 using the P8 spacer. ① Insert the perches 3xPart H into the slots inside the front and back panel of coop.
- Page 9 PRODUCT ASSEMBLY Attach the side panels of nesting box Part I & J to the side of coop by bolt P1x4 on each side. Attached the front panel of nesting box Part K by P3x4 on each side.
- Page 10 PRODUCT ASSEMBLY ① Drop in the bottom panel of nesting box Part L. ② Slide in the divider Part M on each side . ① Attach the roof of nesting box 2xPart N to the nesting box by 4XP6 screws on each side. ② ...
- Page 11 PRODUCT ASSEMBLY Attach the coop roof 2xPart O to the coop by P4x8. Attach the roof cap Part P by P5x4.
- Page 12 PRODUCT ASSEMBLY Attach PVC Waterproof Strip 2xPart Q to the nesting box by P5x4 on each side. Attach the lock P7 to the tray by P6x6. Finish here for only buying one coop...
- Page 13 Notice Read Before Assemble! Pls ignore the following for only one coop owner ! Combination 1 Combination 2 Combination 3...
- Page 14 PRODUCT ASSEMBLY Attach the bottom plate Part S to the run by P3x4. ① Attach the run to the coop by P2x1. ② Connect the run to the coop using P9 by P6x2.
- Page 15 PRODUCT ASSEMBLY Repeat on the other side(Please make sure the run door is open before screwing P2). Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this...
