- Page 1 INSTRUCTION MANUAL AIR 55 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.0x16mm SCREW M3.5x40mm SCREW 21PCS+1 spare 12PCS+1 spare Latch Plastic botton 2PCS Plastic pipe... - Page 5 PARTS Left panel Back panel Front panel Right panel Divider Left tray Right tray Wooden roof Metal lamp tube...
- Page 6 PARTS Wire roof Metal lamp tube Metal lamp tube...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY Attach Front panel Part A to Parts C,D,E by 6xP1 screws. Attach back panel Part B by 6xP1 screws. - Page 9 PRODUCT ASSEMBLY Slide in the tray Part F & G from left and right side. Screw the roof Parts H,L to the house with the hinges by 8xP2 screws.
- Page 10 PRODUCT ASSEMBLY Complete the roof by screwing the latch 2xP3 by 8xP2 screws. Rota the metal lamp holder firstly.
- Page 11 PRODUCT ASSEMBLY Screw it to the cage using the P4 by 2xP2 screws on the upper part; then screw the lower part P5 by 3xP2 screws. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
