Summary of Contents for aivituvin AIR 64
- Page 1 INSTRUCTION MANUAL AIR 64 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 30MIN. ASSEMBLY HARDWARE M3.5x40mm SCREW M4.0x60mm SCREW 16PCS+1spare 3PCS+1spare M3.0x16mm SCREW M3.5x25mm SCREW 23PCS+1spare 20PCS+1spare Hinge Plastic Feet 6PCS 2PCS Connector M3.0x20mm SCREW 17PCS 68PCS+1spare... - Page 4 PARTS CARTON 1/2 Roof-right Roof-left Bottom floor 2PCS Left side panel Waterproof Strip Hardware bag...
- Page 5 PARTS CARTON 2/2 Divider panel Front panel-right PVC curtain Back panel-left Back panel-right Front panel-left...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Pls line up the Part C & Part D as shown on the picture before attach the ① Part A & B to Part C & D by 8xP1. Screw the connector 2XP7 by 8XP8 screws. ② Side Panel (Part C &... - Page 7 PRODUCT ASSEMBLY ① Screw the curtain Part G to the INSIDE of Part F by 3xP3 screws. ② Screw Part H to the INSIDE of Part F by 2xP2 screws. Pls line up the Part C & Part D as shown on the picture before attach the Part F &...
- Page 8 PRODUCT ASSEMBLY ① Screw the divider panel to the bottom panel by 1xP2 screw. ② Screw the connector P7 by 4XP8 screws on each one.
- Page 9 PRODUCT ASSEMBLY Attach 6pcs of plastic feet P6 by 12xP3 screws. Screw the connector 3XP7 to the INSIDE of the roof by 4XP8 screws ① on each one. Screw the roof hinge to the back by 3xP4 screws on each one. ②...
- Page 10 PRODUCT ASSEMBLY Screw the roof hinge P5, one side to the roof by 2xP4 screws, the other ① side to the left side panel by 2xP4 screws. ② Repeat on the other side. Screw the waterproof strip Part L to the OUTSIDE of the roof by 8XP3 screws.
- Page 11 PRODUCT ASSEMBLY Screw the connector 4XP7 by 16XP8 screws each side. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
