Summary of Contents for aivituvin AIR69
- Page 1 NSTRUCTION MANUAL AIR69 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 60MIN. ASSEMBLY HARDWARE M6.0x50 mm BOLT M4.0x40 mm SCREW 8PCS+1 spare 16PCS+1 spare M3.5x60 mm SCREW M3.5x35 mm SCREW 4PCS+1 spare 6PCS+1 spare M3.5x25 mm SCREW M3.0x16 mm SCREW 6PCS+1 spare 28PCS+1 spare Lock Hinge... - Page 4 PARTS Front panel Back panel Left panel Right panel Tray Perch 2PCS Left panel of nesting box Right panel of nesting box Front panel of nesting box 2PCS 2PCS 2PCS...
- Page 5 PARTS Bottom of nesting box Divider of nesting box Roof of nesting box 2PCS 2PCS 2PCS Roof of coop PVC Waterproof Strip Hardware bag 2PCS...
-
Page 6: Product Assembly
PRODUCT ASSEMBLY Attach the front & back panel Part A & B to the side panel Part C & D by 8xP2. ① Slide in the metal tray Part E. ② Insert the perch Part F into the slots inside the front and back panel. - Page 7 PRODUCT ASSEMBLY Attach the side panels of nesting box Part G1 & G2 to the left side of coop by bolt 4xP1. Attach the side panels of nesting box Part G1 & G2 to the right side of coop by bolt 4xP1.
- Page 8 PRODUCT ASSEMBLY Screw the side panel of nesting box to the front panel of nesting box Part H by 4xP2 each side. ① Drop in the bottom of nesting box Part I. ② Slide in the divider Part J.
- Page 9 PRODUCT ASSEMBLY ① Make sure the lock is functioning properly before locking the roof. ② Attachthenesting box roof Part K to the nesting box by 4xP6 each side. Attached PVC Waterproof Strip Part T to the nesting box by 3XP5 each.
- Page 10 PRODUCT ASSEMBLY Attachthecoop roof Part L to the coop by 6xP6. Attach the lock P7 to the tray by 6XP6.
- Page 11 PRODUCT ASSEMBLY Attach the roof hinge P8 to the coop by 4XP6 each side. ① Pls ignore the following for only one coop owner ! ② Attach the run to the coop by 4XP3 screws. Finish...
- Page 12 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this...
