Circutor Computer SMART III FAST 12Vdc Instruction Manual page 63

Computer SMART III FAST 12Vdc
C/K factor
Configuration variable
C/K factor
Program
Configuration variable
Program
Operation type
No� of stages
Configuration variable
No. of stages
Connection and reconnection time
Configuration variable
Connection time
Reconnection time
Alarm: Voltage THD
Configuration variable
Low Value
Hi Value
Alarm: Current x I THD
Configuration variable
Low Value
Hi Value
Alarm: Temperature
Configuration variable
Low Value
Hi Value
Alarm: Leakage Current
Configuration variable
Search for the responsible stage
Value
Stages enabled
Instruction Manual
Table 25:Modbus memory map: programming variables (Table 10)
Address
1138
Table 26:Modbus memory map: programming variables (Table 11)
Address
1139
113A
Table 27:Modbus memory map: programming variables (Table 12)
Address
0-6 (Computer SMART III 6 FAST 12Vdc)
113B
0-12 (Computer SMART III 12 FAST 12Vdc)
Table 28:Modbus memory map: programming variables (Table 13)
Address
113C
113D
Table 29:Modbus memory map: programming variables (Table 14)
Address
1140
1141
Table 30:Modbus memory map: programming variables (Table 15)
Address
1142
1143
Table 31:Modbus memory map: programming variables (Table 16)
Address
1144
1145
Table 32:Modbus memory map: programming variables (Table 17)
Address
1146
1147
1148
Valid data margin
0 - 100 (Value x 100)
Valid data margin
1111-1999
0(FCP), 1(Total), 2(Sim)
Valid data margin
Valid data margin
0-999 network cycles
0-999 network cycles
Valid data margin
0 - 100 %
0 - 100 %
Valid data margin
0 ... 9999 A
0 ... 9999 A
Valid data margin
0 - 80 ºC
0 - 80 ºC
Valid data margin
0 (OFF), 1 (ON)
10 - 1000 mA
0 (No), 1 (Yes)
Default value
100
Default value
1111
0
Default value
6
12
Default value
10
50
Default value
5
8
Default value
4
5
Default value
65
70
Default value
0
300
0
63
