Electrical Connections
4.3 Cable Dimensions
Input
Pt 1000
0 – 10 V
Pulse
Digital
Output
Relay (pump control)
3-point control (230 V
motor valve control)
3-point control (24 V
motor valve control)
0 – 10 V (24 V motor
valve control)
12
Figure 10. Loop terminals
The wiring standard outlined in the table below should be observed:
Cable length
0 – 50 m
50 – 100 m
100 – 200 m
Note:
When choosing cable type and dimension for installation, local government regu-
lations and applicable international directives must be observed at all times.
Note:
Wire resistance can cause measurement error. For example, a resistance of 4 Ω
corresponds to a measured temperature increase of about 1 degree.
EI.65.D4.02
Cross section
Cable Screen
≥ 0.4 mm
2
When connecting long cables to
≥ 0.75 mm
2
inputs, it is recommended to select
≥ 1.5 mm
2
a cable type with screen
2
0.4 – 1.5 mm
2
0.4 – 1.5 mm
2
0.4 – 1.5 mm
2
0.75 – 1.5 mm
2
0.75 – 1.5 mm
2
0.4 – 1.5 mm
2
0.4 – 1.5 mm
