4. Disassembling the valve
4.1 Fix the valve on the disassembly table !
4.2 Identify the valve using the rating plate:
A rating plate is fi tted on every control valve for identifi cation. In principle there are
two diff erent rating plates, their information content is however identical.
• Rating plate "Type IT" for pneumatic linear actuators with internal air conduction.
• Rating plate "Type PB" for pneumatic linear actuators with external air conduction.
Rating plate "Type IT"
Rating plate "Type PB"
4
All manuals and user guides at all-guides.com
Data Field 1
The series number is in this fi eld. It is made up
e.g. as follows:
06078001001
06
078
001
001
The series number and the "part" required must
always be quoted when ordering Spare Parts.
Alternatively you can order using the part no. in
the Spare Parts List at your own risk.
Telephone: 0043 4242 41181 - 0
e-mail: schmidt@fl owserve.com
Data Field 2 and 3
These fi elds clearly identify the:
marked in detail. This helps you to fi nd the steps
described at the end.
06 = Calendar year 006
2 = Order ( 1 = Quotation )
= consecutive series number
= Item within the series number
= ascending quantity within the item
• Body Type
(Page 5)
• Trim Type
(Page 30 - 32)
• Bonnet Type
(Page 34 - 36)
• Packing Type
(Page 61 - 62)
Schmidt Armaturen
