Di s as s em b ly
S tep 03
R ea s s em bly
S tep 03
After work step "Reassembly"
• Twist Special Tool
(Ring-nut)
and put in place slowly
CAU TIO N !
Ensure it hangs vertically !
• Remove fl at gasket (1.2)
CAU TIO N !
Remove remains of fl at gasket (1.2) in the body
and on the bonnet.
Do not damage sealing surface !
S tep 0 6
• Insert fl at gasket (1.2)
CAU TIO N !
Use new fl at gasket (1.2) !
• Twist Special Tool
(Ring-nut)
and put in place slowly
CAU TIO N !
Ensure it hangs vertically !
Schmidt Armaturen
AI - FlowTop
on the stem
on the stem
