D i st rib u ti n g Va lve
SPM - Code : V7xx WxVNA . . . VOTP2LG
Di s as s em b ly
S tep 01
R ea s s em bly
S tep 01
• Unscrew hexagon nuts (3.6)
• Remove washer (3.8) and gland fl ange (3.4)
• Tighten the hexagon nuts of the gland (3.6)
using the torque wrench
CAUT IO N !
Tightening moment of the hexagon nuts (3.6)
as per variant drawing (Page 61 - 63)
