Di s as s em b ly
S tep 02
R ea s s em bly
S tep 02 not app lica ble
Reassembling the packing unit see
• Unscrew hexagon nuts (3.6)
• Remove washer (3.8) and gland fl ange (3.4)
Schmidt Armaturen
AI - FlowTop
S te p 07
