Checking Your Connections; Connecting To The Power Outlet; Powering On - Aztech Easy Start Manual

2.3

Checking Your Connections

NOTE: Please check your connections before proceeding.
Ensure all connections are carefully plugged in as shown in Fig 1-9.
Back view of
ADSL Router
To your
Telephone
Wall Socket
(ADSL Line)
2.4

Connecting to the Power Outlet

See Fig 1-10 for connection to the power outlet.
Back View of the
ADSL Router
2.5

Powering ON

a) Power ON the Power Outlet that is connected to your ADSL Router.
b) Power ON your Computer(s)/Notebook(s).
ADSL2+ 4-Port Ethernet USB Wireless-G Router - Easy Start
To the Ethernet Port on your
Computer(s)/Notebook(s)
Figure 1-9 : Checking Connections
Figure 1-10 : Connecting Power Outlet
To your
Power Outlet
Connect the other end of
the Power Adapter to the
Power
