NOTE: This is important especially if you have more than one Local Area
Connection icons displayed at the Network and Dial-up Connections /
Network Connections window. Ensure that you have selected the correct
one.
1. Select Internet Protocol (TCP/IP) and click Properties. See Fig 1-13.
2. Select the option Obtain an IP address automatically and click OK. See Fig 1-14.
3. Click OK again to close.
4. Ensure that your ADSL Router is powered ON.
5. Restart your system.
6. Proceed to
Chapter 5.
ADSL2+ 4-Port Ethernet USB Wireless-G Router - Easy Start
Figure 1-13 : Local Area Connection properties
Figure 1-14 : TCP/IP Properties
Page 18 of 46
