Chapter 2 - Connecting the ADSL Router to Your PC /
Power off your Computer/Notebook or/and any connected devices before
connecting to the ADSL Router!
2.1

Connecting to the Ethernet

Connect your computer(s)/notebook(s) to the Wireless-G ADSL Router as illustrated. The
following illustration shows the connection of a single computer. See Fig 1-6.
Back View of
ADSL Router
Ethernet
Network Cable
Do not be mistaken by an Ethernet Port and a Line Port. Picture A below illustrates an Ethernet
port, whilst Picture B shows a Line port.
Notebook
WARNING !
Ethernet Port
Figure 1-6 : Connecting to Ethernet
A : ETHERNET
ADSL2+ 4-Port Ethernet USB Wireless-G Router - Easy Start
Back view of a
Computer
Ethernet
Network Card
B : LINE
Page 13 of 46
