INTER-M P.A CONVERGENCE SYSTEM

To setup SETUP PROGRAM

To setup SETUP PROGRAM
Setup Program performs automatic allocation of SP-100 ID, input unit setup, Emergency contact setup, SR-
100 Key setup, and setup and transmission of volume and EQ setup to SP-100. Setup process consists of 6
total steps.
1. SP-100 setup [Step 1]
1) Automatic and manual ID setup of SP-100 unit
[Manual setup]
- Input of Amplifier numbers: Input total numbers of SP-100.
- Select [Manual ID Set].
- Press the [ADD] button.
- Able to check that items of label called as [NEW_AMP_ID_] are added to the list.
38
IPC SYSTEM
Enable to perform automatic or manual ID setup of SP-100 unit, CONTROL
INPUT/OUTPUT setup, volume and EQ setup, and addition and labeling of zone.
[Automatic setup]
- Input of Amplifier numbers: Input total numbers of SP-100.
- Select [Auto ID Set].
- Press the [ADD] button.
