8. EM ERGEN CY BROADCASTIN G SW ITCH
This is a switch used for MIC broadcasting in all zones in emergency.
9. M AIN SW ITCH
This is a short-cut key to change to the Main Control screen of operation program.
10. SCHEDULE SW ITCH
This is a short-cut key to change to the Schedule Setup/ Check screen of operation program.
11. AUDIO SW ITCH
This is a short-cut key to change to the Audio Setup screen for control of sound source volumes such as
BGM, CDP, MP3 and AC97 which are input.
12. SYSTEM SW ITCH
This is a short-cut key to change to the System Status screen of such as zone status or remote connection
status of the AMP (SP-100).
13. M ON ITORIN G SW ITCH
This is a short-key for selecting monitoring function, which is used for checking broadcasting status of the
zone where broadcasting is currently done.
14. M IC UN IT
This is a built-in MIC unit used for emergency broadcasting or MIC broadcasting.
15. TALK SW ITCH
This is a M IC broadcasting switch. It is possible to broadcast by selecting the zone and perform
broadcasting for MIC broadcasting.
16. 15 IN CH LCD TOUCH SCREEN
It is possible to control and check current operation status of the system with a 15inch LCD monitor. A touch
screen function is provided, which enable to simply operate the system with a keyboard or mouse.
