IN TER-M P.A CO N VERGEN CE SYSTEM
(Example : W hen turning on N o.1 and N o.3, the unit number becomes 5 with addition of the relevant actual
number of 1 and 4.)
- CHIME switch (5) : Select whether or not CHIME broadcasting exists.
4. DATA & AUDIO CON N ECTOR
Construction and maintenance is convenient because of receiving and transmitting DATA&AUDIO signal in a
line with a RJ45 Jack.
5. M ON ITOR/ M IC/ AUX VOLUM E
- Monitor Volume: Adjusts volume of the monitor speaker.
- MIC Volume: Adjusts volume of the MIC.
- AUX Volume: Adjusts volume of the AUX.
6. AUX IN PUT
This terminal is used to broadcast external sound source to be input with the AUX IN connector, through the
SR-100.
Broadcasting mixed with a MIC sound source is output.
Caution : Please connect an expansion keypad (SR-10KR) to the SR-100 in the power-off status.
