1) Connect SI-100 and SR-100 using a CAT5 wire.

2) Set ID Setting to 1 through 8 in the back side.

Caution : For supplying power to a DC 12V adapter.

- W hen expanding a keyboard using a SR-100KP.

- W hen distance between SI-100 and SR-100 is more than 50m.
