6. POW ER CORD
This is an AC power cord for connecting power to the system.
Caution : Connect cords to the socket after checking voltage available. Since there is no DC input in this
unit, always use UPS for installation.
7. ETHERN ET OPERATION STATUS DISPLAY LED
W here Ethernet is normally connected, this is a LED to display data communication status.
8. ETHERN ET CON N ECTION DISPLAY LED
W here Ethernet is normally connected, this is a LED to display connection status. If a LED is not turned on,
check connection status again.
9. ETHERN ET PORT
This is a port to connect to Ethernet using a RJ45 Jack. This supports 10/ 100M Base-T Fast Ethernet.
10. EXTERN AL SERIAL CON TROL TERM IN AL
This is a remote control terminal to control our CD/ TUN ER, etc.
11. SR-100 CON N ECTION TERM IN AL
This is a terminal to connect SR-100, up to 8pcs. See [Manufacturing Cable] in page 36 for method to
connect connectors.
12. DIGI-LIN K CON TROL PORT
Connecting device capable of controlling a DIGI-LIN K such as CD, DECK and TUN ER enables to remotely
control.
Caution : It is impossible to use as a DIGI-LIN K CO N TRO L with our DECK(PC-9335AD).
13. SP-100 CON N ECTION TERM IN AL
This is a terminal to connect the SP-100.
14. FIRE EM ERGEN CY CON TACT TERM IN AL
This is a fire emergency contact input terminal to perform emergency broadcasting to the setup zone where
fire occurs. Up to 64 channels can be setup.
