INSTALLING THE LIGHT KIT

NOTE: Before staring the installation, disconnect the power by turning off the
circuit breaker or removing the fuse at fuse box.
Step 1. Loosen the 3 screws from the switch housing.
Step 2. Raise and hold the light kit close to the switch housing. Snap
together the wire connection plugs (Fig. 16).
Step 3. Carefully push all wires back into the switch housing, then install the
light kit assembly onto the mounting ring with 3 screws provided. Be sure
to tighten all screws (Fig. 16).
14 | KICHLER.COM
Mounting ring
Connection plugs
Light kit
assembly
Fig. 16
Screws
Pull chain
Pull chain
