- Page 1 Sutter Place Premier ® ™ A Kichler Select ceiling fan Kichler ® Lighting 7711 East Pleasant Valley Road P.O. Box 318010 Instruction Manual Cleveland, Ohio 44131-8010 Customer Service 866.558.5706 8:30 AM to 5:00 PM EST, Monday - Friday...
- Page 2 1. SAFETY RULES 1. To reduce the risk of electric shock, insure 10. Do not use water or detergents when electricity has been turned off at the circuit cleaning the fan or fan blades. A dry dust breaker or fuse box before beginning. cloth or lightly dampened cloth will be suitable for most cleaning.
- Page 3 Sutter Place Premier 2. TOOLS AND MATERIALS REQUIRED Philips screw driver Blade screw driver 11 mm wrench Step ladder Wire cutters 3. PACKAGE CONTENTS Unpack your fan and check the contents. You should have the following items: Fan blades (5) Ceiling mounting bracket Canopy Ball/downrod assembly...
- Page 4 4. MOUNTING OPTIONS If there isn't an existing UL (cUL for Canadian Installation) listed mounting box, then read the following instructions. Disconnect the power by removing fuses or turning off circuit breakers Secure the outlet box directly to the building Outlet box structure.
- Page 5 Sutter Place Premier 5. HANGING THE FAN NOTE: This ceiling fan is supplied with two UL Listed outlet box types of hanging assemblies; a downrod and canopy mounting system and a "close to ceiling" Canopy ONLY system. The "close-to- Washers Ceiling mounting ceiling"...
- Page 6 Step 4. Slip the coupling cover and canopy onto the downrod as Figure 7. Thread the hanger ball onto the downrod, insert the cross pin previously removed from Registration slot the ball/downrod assembly through the downrod and tighten. Now tighten the set Check tab screw previously loosened.
- Page 7 Sutter Place Premier 6. INSTALLATION OF SAFETY SUPPORT (required for Canadian installation ONLY) A safety support cable is provided to help prevent the ceiling fan from falling, please install it as follows. Step 1. Attach the provided wood screw and Ceiling mounting Attach bracket...
- Page 8 8. FINISHING THE INSTALLATION Outlet box STANTARD CEILING INSTALLATION STANTARD CEILING INSTALLATION Screws Step 1. Tuck all the connections neatly into the Ceiling mounting ceiling outlet box. bracket Screws Step 2. Slide the canopy up to ceiling and attach the canopy to the ceiling mounting bracket using 4 screws at the top edge of the Canopy mounting bracket.
- Page 9 Sutter Place Premier 9. ATTACHING THE FAN BLADES CAUTION: Remove the five rubber shipping blocks attached to the face of the motor. These blocks keep the motor from shifting during shipping and MUST be removed during installation. Step 1. Attach a blade to a blade bracket using the screws, metal washers and fiber washers provided.
- Page 10 11. INSTALLING THE LIGHT FIXTURE 1. While holding the light fixture assembly under your ceiling fan, push the square wire connectors together. One from the fan and one from the light fixture. (Fig.18) NOTE: These connectors are color coded and will ONLY engage when the colored strips are matched (aligned).
- Page 11 Sutter Place Premier 12. OPERATING INSTRUCTIONS Turn the power on and check the operation of your ceiling fan. The "center" pull chain turns the light fixture On and Off. The "outside" pull chain controls the 3 speeds of your ceiling fan. 1 pull = High, 2 pulls = Medium, 3 pulls = Low and the 4th pull turns the motor off.
- Page 12 13. TROUBLESHOOTING Problem Solution Fan will not start. 1. Check that all fuses or circuit breakers are installed or in the ON position. 2. Check all electrical connections to insure proper contact. CAUTION: Make sure the main power is OFF when checking any electrical connection. Fan sounds noisy.
