Check Point QUANTUM SPARK 1595R Getting Started Manual page 33

Key Item
1 Reset
2 Bypass
(Wired
only)
3 Factory
Default
4 SD card
slot
5 SIM card
slot
Description
Short press resets the system, but does not remove any user parameters.
The Bypass mechanism is activated between the DMZ port and LAN-4 port upon
software or hardware failure. Traffic is unsecured when the bypass mechanism is
activated.
Press the button continuously for 12 seconds to restore the appliance to its
factory default.
Removes all user parameters previously configured.
Insert micro-SD card here.
Insert SIM card here (Cellular model only).
Quantum Spark 1595R Getting Started Guide | 33
Side Panels
