Check Point 13000 Replacing

Replacing appliance cooling fans

Hide thumbs Also See for 13000:

Replacing 13000 Appliance

705955

Protected

2014

Important - To protect the appliance and the cooling fans from electrostatic

discharge damage, make sure that you are properly grounded before you

touch any of the electronic components. Read the Health and Safety

Information in the 13000 Appliance Getting Started Guide before you start to

prepare the appliance.

We recommend that you use a grounding wrist strap. The grounding plug on

the rear of the appliance provides a chassis grounding point.

You can hot swap one or more of the four cooling fans.

Item

Description

Cooling fan number 1

Cooling fan number 2

Cooling fan number 3

For a list of our Third Party Copyright notices, please refer to:

Classification [Protected]

For a list of our trademarks, please refer to: http://www.checkpoint.com/copyright.html.

http://www.checkpoint.com/3rd_party_copyright.html

P/N:705955 | 1

Table of Contents

Do you have a question about the 13000 and is the answer not in the manual?

Page 1 Read the Health and Safety Information in the 13000 Appliance Getting Started Guide before you start to prepare the appliance. We recommend that you use a grounding wrist strap. The grounding plug on the rear of the appliance provides a chassis grounding point.
Page 2 Item Description Cooling fan number 4 Cooling fan screws ESD ground plug Caution - Components inside the appliance can overheat if they are not cooled even for a short period of time. To prevent damage from too much heat:  If two or more cooling fans fail, we recommend that you shut down the appliance ...
Page 3 Hold the screws and pull the cooling fan away from the appliance. Insert the replacement cooling fan and push it into the appliance. Tighten the screws on the cooling fan unit.
