Yamaha MIO Service Manual page 49

1 Tail/brake light assembly
2 Tail/brake light assembly coupler
3 Fuel sender lead
4 A.C. magneto lead couplers
5 Spark plug lead
6 Ignition coil
7 Negative battery lead
8 Ignition coil lead
9 A.C. magneto lead
0 Wire harness
A Rectifier/regulator
1
B
1
A
2
È
É
3
A
È
0
Ê
3
A
CABLE ROUTING
B C.D.I. unit
C Positive battery lead
D Starter relay lead
E Fuse lead
F Fuse
G Starter relay
H Starter motor lead
È Fasten the wire harness with the holders.
É Pass the fuel sender lead through the hole in the
fuel tank rubber damper.
Ï
Î
Ì
Í
Ì
È
4
È
9
8
7
6
2 - 29
SPEC
C D E
Ë
F
G
7
H
B
Ë
B
5
