Ordering Information; Bill Of Materials - Analog Devices EVAL-AD5252SDZ User Manual

UG-274

ORDERING INFORMATION

BILL OF MATERIALS

Table 7.
Qty Reference Designator
1 C1
4 C2, C4, C25, C26
1 C3
2 C24, C27
1 D6
1 J1
1 J2
1 J22
4 A20, A21, A24, A25
3 A27, A29, A30
4 BUF-W1, OAVOUT, BUF-3, BUF-4
1 R41
2 R1, R2
5 R3, R4, R38, R39, R40
36 AD5162-1, AD5162-2, AD5172-1,
AD5172-2, AD5204-1, AD5204-2,
AD5204-3, AD5204-4, AD5222-1,
AD5222-2, AD5232-1, AD5232-2,
AD5233-1, AD5233-2, AD5233-3,
AD5233-4, AD5235-1, AD5235-2,
AD5243-1, AD5243-2, AD5252-1,
AD5252-2, AD5254-1, AD5254-2,
AD5254-3, AD5254-4, AD8403-1,
AD8403-2, AD8403-3, AD8403-4,
ADN2850-1, ADN2850-2, R34, R35,
R42, R43
1 R37
6 3.3 V, 5 V, DGND, AGND, VDD, VSS
35 A1, A2, A3, A4, RDY|MODE, RESET_BF,
SCL_BF, SCLK_BF, SDA_BF, SDO_BF,
SHDN_BF, SYNC_BF, MUX-A0|CS,
MUX-A1|DACSEL, MUX-A2|U/D, O1, O2,
DIN_BF, CLK, B1, B2, B3, B4, V1, V2, VOUT,
VOUT2, VOUT3, VOUT4, W1, W1_BUF, W2,
W3, W4, WP_BUF
1 U1
1 U2
1 U3
1 U4
1 U5
1 U6
1 U7
1 U8
1 U9
1 U10
1 U11
1 U12
1 U13
1 U14
1 U15
1 A22
1 U25
1 FEC refers to Farnell Electronic Component Distributors; Digi-Key refers to Digi-Key Corporation.
Description
10 nF capacitor, 0805
0.1 µF capacitor, 0603
1 µF capacitor, 0402
10 µF capacitor, 1206
LED, green
3-pin connector
2-pin connector
Receptacle, 0.6 mm, 120 way
Header, 2-row, 36 + 36 way, and jumper socket, black
Header, 1-row, 3-way, and jumper socket, black
Header, 1-row, 2-way, and jumper socket, black
1.78 kΩ resistor, 0603, 1%
2.2 kΩ resistor, 0603, 1%
2.7 kΩ resistor, 1206, 1%
0 Ω resistor, 0603
1 kΩ resistor, 0603, 1%
Test point, PCB, black, PK100
Test point, PCB, red, PK100
AD5243
AD5162
AD5172
AD5233
AD5222
AD8403
AD5254
AD5204
AD5252
AD5232
AD5235
ADN2850
ADG3247
AD8618
AD8652
ADG658
24LC64
Rev. 0 | Page 14 of 16
Evaluation Board User Guide
1
Supplier /Part Number
FEC 1692285
FEC 138-2224
FEC 1288253
FEC 1611967
FEC 579-0852
FEC 151790
FEC 151789
Digi-Key H1219-ND
FEC 148-535 and FEC 150-410
FEC 102-2248 and FEC 150-410
FEC 102-2247 and FEC 150-410
FEC 1170811
FEC 933-0810
FEC 9337288
FEC 9331662
FEC 933-0380
FEC 873-1128
FEC 873-1144
Analog Devices AD5243
Analog Devices AD5162
Analog Devices AD5172
Analog Devices AD5233
Analog Devices AD5222
Analog Devices AD8403
Analog Devices AD5254
Analog Devices AD5204
Analog Devices AD5252
Analog Devices AD5232
Analog Devices AD5235
Analog Devices ADN2850
Analog Devices ADG3247
Analog Devices AD8618
Analog Devices AD8652
Analog Devices ADG658
FEC 975-8070
