Operation
thicknessSENSOR
7 The zoom function scales the time axis during both the measurement and the
offline analysis.
8 Mouseover function. When moving the mouse over the graphic in stopped state,
curve points are marked with a circle symbol and the related values are displayed
in a text box above the graphic.
9 Scaling of the x-axis can be defined by means of an input field below the time axis.
10 Scaling of the x-axis: When the measurement is running, you can use the left slider
to enlarge (zoom) the total signal. If the diagram is stopped, you can also use the
right slider. The zoom window can also be moved with the mouse in the center of
the zoom window (arrow cross).
If the language is set to German, the measured values are stored with a comma as a
decimal separator, otherwise with a period.
i
Only a limited number of recorded measurements can be stored (about 50000). If
more measured values are recorded, the oldest measured values are deleted.
