Mounting
thicknessSENSOR
5.5.8
Connector and Sensor Cable
Never fall below the bending radius for the sensor cable of 30 mm (fixed) resp. 60
mm (dynamic).
i
Unused open cable ends must be insulated or bluntly cut to protect against short
circuits or sensor malfunctions.
Avoid excessive pull on the cables. If a cable of over 5m in length is used and it
hangs vertically without being secured, make sure that some form of strain relief is
provided close to the connector.
Connect the cable shield to the potential equalization (PE, protective earth conduc-
tor) on the evaluator (switching cabinet, PC housing) and avoid ground loops.
Never lay signal leads next to or together with power cables or pulse-loaded cables
(e.g. for drive units and solenoid valves) in a bundle or in cable ducts. Always use
separate ducts.
Recommended strand cross-section for self-made connection cables: ≥ 0.14 mm².
