Connect Sensor+ hardware
3. When you wake Connect Sensor+, the LED indicators light up in a
the device wakes up.
4. Close the cover on the device. The cover snaps into place.
Note The Connect Sensor+ enclosure may require some force to close. This is intended as part
of the design to ensure a robust seal in damp or dusty environments. For details about closing
the Connect Sensor+ enclosure, see

Connect Sensor+ LED start-up sequence

The LED indicators light up in a predetermined sequence when you manually wake the Connect
Sensor+. For a description of where the LEDs are located on the device, see
1. Press the Wake button inside the device or swipe a magnet across the device.
2. The cellular and battery LEDs light up purple for one second and then turn off.
3. The sensor LED blinks green as readings are taken and then turns off when readings are
complete.
4. If Bluetooth is enabled, the Bluetooth LED blinks yellow for 30 seconds. If a Bluetooth device is
attached, the Bluetooth LED turns solid and remains lit.
Note If Bluetooth is not enabled, the Bluetooth LED does not light up.
5. Connect Sensor+ takes and pushes data readings.
a. The cellular LED blinks red while the Connect Sensor+ attempts to bring up the
b. The Connect Sensor+ takes a battery life reading. The battery LED blinks either blue
c. The cellular LED blinks blue until the connection to SkyCloud is complete.
d. The Connect Sensor+ pushes the data. When the data transfer is complete, the
e. After a few seconds, the cellular LED turns off.

Closing the Connect Sensor+

All Connect Sensor+ products are shipped to you closed. You will need to open the device to install the
battery, the SIM card, and to wire third-party sensors to the Connect Sensor+ I/O interface. After you
have opened the enclosure, it may require some force to close. This is intended as part of the design
to ensure a robust seal in damp or dusty environments.
If you have problems closing the enclosure after either of these operations, please follow these
instructions:
1. Ensure the gasket is fully seated in the groove on the enclosure.
2. Place the device on a flat, stable surface.
3. Apply pressure to the top of the Connect Sensor+ and pull the front door clip closed with your
finger.
Welcome to Digi SkyCloud
Closing the Connect
modem and connect to the cellular network.
or red, depending on the status of the battery life.
cellular LED is solid blue.
Closing the Connect Sensor+
predetermined sequence
Sensor+.
SkyCloud LEDs.
as
