Digi Connect SP Quick Start Manual

Quick Start
Guide
Digi Connect® SP and Wi-SP
2 Connect the hardware
Digi Connect SP:
1. Connect the power supply to the power connector.
2. Connect the Ethernet cable to the Ethernet port.
3 Download the required software and documentation
1. Navigate to www.digi.com/products/serial-servers/wireless-serial-servers/digiconnectwisp, and click the Utilities link under the Product Support tab.
2. Select your operating system. A list of available utilities for your operating system appears.
3. Download and run either the Device Discovery Utility or Digi Port Authority - Remote.
If the serial ports for your product will be managed using Digi's RealPort software, download the RealPort driver.
1. Navigate to www.digi.com/products/serial-servers/wireless-serial-servers/digiconnectwisp, and select Drivers under the Product Support tab.
2. Select your operating system. A list of available downloads and release notes for your operating system appears.
3. Download the RealPort driver and the release notes.
Note For Microsoft Windows operating systems, unzip the download package and run the executable. For Linux or UNIX operating systems, follow the instructions in the
release notes.
For additional support, download product support documentation.
1. Navigate to www.digi.com/products/serial-servers/wireless-serial-servers/digiconnectwisp.
2. Click the Product Support tab.
3. Navigate to the product documentation and other available resources as needed.
4 Connect to the network
Note This section requires serial terminal software, such as Hyperterm or PuTTY. Download one of these programs if you do not have one installed.
Configure Digi Connect SP
Use the Digi Discovery Utility or Digi Port Authority - Remote to discover devices on your network and open the web interface.
1. In the list of discovered devices, select the Digi Connect SP device.
2. Using the Digi Discovery Utility or Digi Port Authority, configure the IP address if necessary.
3. Open the Digi Connect SP web interface. In the Device Discovery Utility, click Open web interface. In Digi Port Authority-Remote, click Device Configuration.
4. A login prompt for the web interface appears. Enter the default username and password: root and dbps. Continue to section 5.
Configure Digi Connect Wi-SP
There are two methods to configure the network connection on a Digi Connect Wi-SP. Use the method you prefer.
Method 1: Use an access point preconfigured with the default SSID of CONNECT with no encryption and let the Digi Connect Wi-SP associate to it.
1. Once the device has associated, use the Digi Discovery Utility or Digi Port Authority - Remote to discover devices on your network and open the web interface.
2. In the list of discovered devices, select the Digi Connect Wi-SP device.
3. Using the Digi Discovery Utility or Digi Port Authority, configure the IP address if necessary.
4. Open the Digi Connect Wi-SP web interface. In the Device Discovery Utility, click Open web interface. In Digi Port Authority-Remote, click Device Configuration.
5. A login prompt for the web interface appears. Enter the default username and password: root and dbps. Continue to section 5.
© 2016 Digi International Inc.
Digi, Digi International, and the Digi logo are trademarks or registered trademarks in the United States and other countries worldwide. All other trademarks mentioned in this document are the
property of their respective owners.
1 Verify your components
Verify that you have all included equipment. If any item is missing or damaged, contact your supplier.
Included equipment
or
Required additional equipment
Digi Connect Wi-SP:
1. Connect the power supply to the power connector.
2. Connect the Wi-Fi antenna to the antenna connector.
