Flowmeter Proline 200
Parameter overview with brief description
Parameter
Device tag
8.6

Protecting settings from unauthorized access

The following write protection options exist in order to protect the configuration of the
measuring device from unintentional modification:
• Protect access to parameters via access code
• Protect access to local operation via key locking
• Protect access to measuring device via write protection switch
• Protect access to parameters via block operation
For detailed information on protecting the settings against unauthorized access, see the
Operating Instructions for the device.
8.7

Application-specific commissioning

8.7.1 Steam application
Select medium
Navigation:
Setup → Medium selection
1. Call up the Medium selection wizard.
2. In the Select medium parameter, select the Steam option.
3.
When pressure measured value is read in
In the Steam calculation mode parameter, select the Automatic (p-/T-compensated)
option.
4. If pressure measured value is not read in:
In the Steam calculation mode parameter, select the Saturated steam (T-
compensated) option.
5. In the Steam quality value parameter, enter the steam quality present in the pipe.
 Without Wet Steam Detection/Measurement application package: Measuring
device uses this value to calculate the mass flow of the steam.
With Wet Steam Detection/Measurement application package: Measuring device
uses this value if the steam quality cannot be calculated (steam quality is not
compliant with basic conditions).
1) Sensor version option "mass (integrated pressure and temperature measurement)", Pressure read in via FF
Endress+Hauser
Description
Enter the name for the
measuring point.
User interface
Max. 32 characters such as
letters, numbers or special
characters (e. g. @, %, /)
1)
:
Commissioning
Factory setting
EH_Prowirl_200_xxxxxxxx
xxx
