Operation options
Numeric editor
Confirms selection.
Exits the input without applying the changes.
Inserts minus sign at the input position.
–
6.3.4 Operating elements
Keys and meaning
Enter key
For operational display
• Pressing the key briefly opens the operating menu.
• Pressing the key for 2 s opens the context menu.
In a menu, submenu
• Pressing the key briefly
– Opens the selected menu, submenu or parameter.
– Starts the wizard.
– If help text is open:
Closes the help text of the parameter.
• Pressing the key for 2 s for parameter:
If present, opens the help text for the function of the parameter.
With a wizard: Opens the editing view of the parameter.
With a text and numeric editor:
• Pressing the key briefly
– Opens the selected group.
– Carries out the selected action.
• Pressing the key for 2 s:
Confirms the edited parameter value.
Minus key
• In a menu, submenu: Moves the selection bar upwards in a choose list.
• With a wizard: Confirms the parameter value and goes to the previous parameter.
• With a text and numeric editor: Moves the selection bar to the left (backwards) in an input screen.
Plus key
• In a menu, submenu: Moves the selection bar downwards in a choose list.
• With a wizard: Confirms the parameter value and goes to the next parameter.
• With a text and numeric editor: Moves the selection bar to the right (forwards) in an input screen.
+ Escape key combination (press keys simultaneously)
In a menu, submenu
• Pressing the key briefly
– Exits the current menu level and takes you to the next higher level.
– If help text is open, closes the help text of the parameter.
• Pressing the key for 2 s for the parameter: Returns you to the operational display ("home position").
With a wizard: Exits the wizard and takes you to the next higher level.
With a text and numeric editor: Closes the text or numeric editor without applying changes.
+ Minus/Enter key combination (press the keys simultaneously)
32
Moves the input position one position to the left.
Inserts decimal separator at the input position.
.
Clears all entered characters.
