KA01327D/06/EN/02.18
71423497
2018-12-03
Products
Brief Operating Instructions
Flowmeter
Proline 200
FOUNDATION Fieldbus transmitter
with vortex flow sensor
These instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Brief Operating Instructions part 2 of 2: Transmitter
Contain information about the transmitter.
Brief Operating Instructions part 1 of 2: Sensor →  3
Solutions
Services

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Flowmeter Proline 200 and is the answer not in the manual?

Questions and answers

Related Manuals for Endress+Hauser Flowmeter Proline 200

Summary of Contents for Endress+Hauser Flowmeter Proline 200

  • Page 1 Products Solutions Services KA01327D/06/EN/02.18 71423497 2018-12-03 Brief Operating Instructions Flowmeter Proline 200 FOUNDATION Fieldbus transmitter with vortex flow sensor These instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Brief Operating Instructions part 2 of 2: Transmitter Contain information about the transmitter.
  • Page 2 Flowmeter Proline 200 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
  • Page 3 These Brief Operating Instructions are the Brief Operating Instructions part 2: Transmitter. The "Brief Operating Instructions part 1: Sensor" are available via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App Detailed information about the device can be found in the Operating Instructions and the other documentation: • Internet: www.endress.com/deviceviewer •...

  • Page 4: Table Of Contents

    Table of contents Flowmeter Proline 200 Table of contents Document information ............5 Symbols used .

  • Page 5: Document Information

    Flowmeter Proline 200 Document information Document information Symbols used 1.1.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in WARNING serious or fatal injury.
  • Page 6 Document information Flowmeter Proline 200 Symbol Meaning Protective Earth (PE) A terminal which must be connected to ground prior to establishing any other connections. The ground terminals are situated inside and outside the device: • Inner ground terminal: Connects the protectiv earth to the mains supply.

  • Page 7: Basic Safety Instructions

    Flowmeter Proline 200 Basic safety instructions Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣ Are authorized by the plant owner/operator.

  • Page 8: Workplace Safety

    Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties.

  • Page 9: Device-Specific It Security

    Flowmeter Proline 200 Product description Device-specific IT security The device offers a range of specific functions to support protective measures on the operator' s side. These functions can be configured by the user and guarantee greater in-operation safety if used correctly.
  • Page 10 Installation Flowmeter Proline 200 4.1.1 Wall mounting 19 (0.6) 80 (3.15) A0033484  1 mm (in) 4.1.2 Post mounting 20 70 … ( 0.79 to 2.75) SW 13 A0033486  2 mm (in) Endress+Hauser...

  • Page 11: Turning The Transmitter Housing

    Flowmeter Proline 200 Installation Turning the transmitter housing To provide easier access to the connection compartment or display module, the transmitter housing can be turned. max. 350° 8 mm 8 mm A0032242 Release the fixing screw. Turn the housing to the desired position.

  • Page 12: Transmitter Post-Installation Check

    Installation Flowmeter Proline 200 With display module pulled out: Feed the cable into the gap between the housing and main electronics module and plug the display module into the electronics compartment until it engages. Reverse the removal procedure to reassemble the transmitter.

  • Page 13: Electrical Connection

    Flowmeter Proline 200 Electrical connection Electrical connection Connection conditions 5.1.1 Required tools • For cable entries: Use corresponding tools • For securing clamp: Allen key 3 mm • Wire stripper • When using stranded cables: Crimper for wire end ferrule •...
  • Page 14 Electrical connection Flowmeter Proline 200 5.1.3 Connecting cable for remote version Connecting cable (standard) Standard cable 2 × 2 × 0.5 mm (22 AWG) PVC cable with common shield (2 pairs, pair-stranded) Flame resistance According to DIN EN 60332-1-2 Oil-resistance...
  • Page 15 Flowmeter Proline 200 Electrical connection 5.1.4 Terminal assignment Transmitter Connection version for FOUNDATION Fieldbus, pulse/frequency/switch output A0013570 A0018161 Maximum number of terminals Maximum number of terminals for order code for "Accessory mounted", option NA "Overvoltage protection" Output 1: FOUNDATION Fieldbus...
  • Page 16 Electrical connection Flowmeter Proline 200 For reasons concerning explosion protection, it is recommended that grounding be dispensed with. To comply with both requirements, there are basically three different types of shielding in the fieldbus system: • Shielding at both ends •...
  • Page 17 Flowmeter Proline 200 Electrical connection A0028768  3 Connection example for FOUNDATION Fieldbus Control system (e.g. PLC) Power conditioner (FOUNDATION Fieldbus) Cable shield: the cable shield must be grounded at both ends to comply with EMC requirements; observe cable specifications...
  • Page 18 Electrical connection Flowmeter Proline 200 Supply voltage for a compact version without a local display Order code for "Output" Minimum Maximum terminal voltage terminal voltage Option E: FOUNDATION Fieldbus, pulse/ ≥ DC 9 V DC 32 V frequency/switch output In event of external supply voltage of the power conditioner...

  • Page 19: Connecting The Measuring Device

    Flowmeter Proline 200 Electrical connection Connecting the measuring device NOTICE Limitation of electrical safety due to incorrect connection! ‣ Have electrical connection work carried out by appropriately trained specialists only. ‣ Observe applicable federal/national installation codes and regulations. ‣ Comply with local workplace safety regulations.
  • Page 20 Electrical connection Flowmeter Proline 200 WARNING Housing degree of protection may be voided due to insufficient sealing of the housing. ‣ Screw in the screw without using any lubricant. The threads on the cover are coated with a dry lubricant.
  • Page 21 Flowmeter Proline 200 Electrical connection Connect the transmitter. How the connecting cable is connected in the transmitter housing depends on the measuring device approval and the version of the connecting cable used. In the following versions, only terminals can be used for connection in the transmitter housing: •...
  • Page 22 Electrical connection Flowmeter Proline 200 A0034171  4 Sample graphic Connecting cable (standard, reinforced) Guide the connecting cable through the cable entry and into the connection housing (if using a connecting cable without an M12 device plug, use the shorter stripped end of the connecting cable).
  • Page 23 Flowmeter Proline 200 Electrical connection Reverse the removal procedure to reassemble the connection housing. Connecting the transmitter Connecting transmitter via plug A0034172 ‣ Connect the plug. Connecting transmitter via terminals 3 mm A0034173 Loosen the securing clamp of the electronics compartment cover.
  • Page 24 Electrical connection Flowmeter Proline 200 TX 10 8 mm A0034174 Loosen the locking screw of the transmitter housing. Loosen the securing clamp of the transmitter housing. ~15° A0034175  5 Sample graphic Turn the transmitter housing to the right until it reaches the marking.
  • Page 25 Flowmeter Proline 200 Electrical connection A0034176  6 Sample graphic A0034177  7 Sample graphic Connecting cable (standard, reinforced) Disconnect the signal cable from the connection board of the wall housing . by pressing in the locking clip on the connector. Remove the transmitter housing.

  • Page 26: Ensuring The Degree Of Protection

    Electrical connection Flowmeter Proline 200 11. Connect the cable shield via the cable strain relief. 12. Tighten the screws for the cable strain relief using a torque in the range of 1.2 to 1.7 Nm. 13. Reverse the removal procedure to reassemble the transmitter housing.

  • Page 27: Post-Connection Check

    Flowmeter Proline 200 Electrical connection Firmly tighten the cable glands. To ensure that moisture does not enter the cable entry: Route the cable so that it loops down before the cable entry ("water trap").  A0029278 Insert dummy plugs into unused cable entries.

  • Page 28: Operation Options

    Operation options Flowmeter Proline 200 Operation options Overview of operation options A0032226 Local operation via display module Computer with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370 Field Communicator 475 Control system (e.g. PLC)

  • Page 29: Structure And Function Of The Operating Menu

    Flowmeter Proline 200 Operation options Structure and function of the operating menu 6.2.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation task-oriented Setup Diagnostics Operating menu for experts Expert function-oriented A0014058-EN  8 Schematic structure of the operating menu 6.2.2...

  • Page 30: Access To The Operating Menu Via The Local Display

    Operation options Flowmeter Proline 200 Access to the operating menu via the local display X X X X X X 19.184 mA 12.5 X X X X X X Language 20.50 Ã English Deutsch Español Français Xxxxxxx A B C D E F G H I J K M N O P Q R S T U V W +0.000 Xx...
  • Page 31 Flowmeter Proline 200 Operation options 6.3.1 Operational display Explanatory symbols for the measured value Status area • Depends on the device version, e.g.: The following symbols appear in the status area of the – : Volume flow operational display at the top right: –...
  • Page 32 Operation options Flowmeter Proline 200 Numeric editor Confirms selection. Moves the input position one position to the left. Exits the input without applying the changes. Inserts decimal separator at the input position. Inserts minus sign at the input position. Clears all entered characters.

  • Page 33: Access To The Operating Menu Via The Operating Tool

    Flowmeter Proline 200 System integration Keys and meaning Reduces the contrast (brighter setting). Plus/Enter key combination (press and hold down the keys simultaneously) Increases the contrast (darker setting). Minus/Plus/Enter key combination (press the keys simultaneously) For operational display:Enables or disables the keypad lock.

  • Page 34: Cyclic Data Transmission

    Commissioning Flowmeter Proline 200 Device type ID 0x1038 Device type parameter Diagnostics → Device information → Device type Device revision • On the transmitter nameplate • Device revision parameter Diagnostics → Device information → Device revision DD Revision Information and files under: •...

  • Page 35: Switching On The Measuring Device

    Flowmeter Proline 200 Commissioning Switching on the measuring device ‣ After a successful function check, switch on the measuring device.  After a successful startup, the local display switches automatically from the startup display to the operational display. If nothing appears on the local display or a diagnostic message is displayed, refer to the Operating Instructions for the device →...

  • Page 36: Defining The Tag Name

    Commissioning Flowmeter Proline 200 The desired units can be selected in the System units submenu. The wizards systematically guide the user through all the parameters required for configuration, such as parameters for measurement or outputs. The wizards available in the particular device can vary on account of the device version (e.g.

  • Page 37: Protecting Settings From Unauthorized Access

    Flowmeter Proline 200 Commissioning Parameter overview with brief description Parameter Description User interface Factory setting Device tag Enter the name for the Max. 32 characters such as EH_Prowirl_200_xxxxxxxx measuring point. letters, numbers or special characters (e. g. @, %, /) Protecting settings from unauthorized access...
  • Page 38 Commissioning Flowmeter Proline 200 Configuring the analog input (AI) Configuring the analog input (AI). Configuring the external compensation With Wet Steam Detection/Measurement application package: In the Steam quality parameter, select the Calculated value option. For detailed information on the basic conditions for wet steam applications, see the Special Documentation.
  • Page 39 Flowmeter Proline 200 Commissioning 8.7.3 Gas applications For accurate mass or corrected volume measurement, it is recommended to use the pressure-/temperature-compensated sensor version. If this sensor version is not available, read in the pressure via the FF. If neither of these two options is possible, the pressure can also be entered as a fixed value in the Fixed process pressure parameter.
  • Page 40 Commissioning Flowmeter Proline 200 Select medium Navigation: Setup → Medium selection Call up the Medium selection wizard. In the Select medium parameter, select the Gas option. In the Select gas type parameter, select the Gas mixture option. Configuring gas composition Navigation: Setup →...
  • Page 41 In the Reference temperature parameter enter the temperate for calculating the reference density. Endress+Hauser recommends the use of active pressure compensation. This fully rules out the risk of measured errors due to pressure variations and incorrect entries . Natural gas...
  • Page 42 12. In the Relative density parameter, enter the relative density of the natural gas. Endress+Hauser recommends the use of active pressure compensation. This fully rules out the risk of measured errors due to pressure variations and incorrect entries .

  • Page 43: Diagnostic Information

    Flowmeter Proline 200 Diagnostic information In the Reference Z-factor parameter, enter the value 1. 10. If specific heat capacity is to be measured: In the Specific heat capacity parameter, enter the heat capacity of the fluid. 11. In the Z-factor parameter, enter the value 1.
  • Page 44 Diagnostic information Flowmeter Proline 200 X X X X X X X X X X X X X X 20.50 S801 Supply voltage Menu Diagnostic list Diagnostics 1 S801 Supply voltage Diagnostics 2 Diagnostics 3 Supply voltage (ID:203) S801 0d00h02m25s...
