Brief Operating Instructions
Flowmeter
Proline 300
HART transmitter
with electromagnetic sensor
These instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Brief Operating Instructions part 2 of 2: Transmitter
Contain information about the transmitter.
Brief Operating Instructions part 1 of 2: Sensor → 3
Solutions
Services
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Endress+Hauser Flowmeter Proline 300
Summary of Contents for Endress+Hauser Flowmeter Proline 300
- Page 1 Products Solutions Services KA01308D/06/EN/03.22-00 71574812 2022-08-01 Brief Operating Instructions Flowmeter Proline 300 HART transmitter with electromagnetic sensor These instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Brief Operating Instructions part 2 of 2: Transmitter Contain information about the transmitter.
- Page 2 Flowmeter Proline 300 Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
- Page 3 These Brief Operating Instructions are Brief Operating Instructions Part 2: Transmitter. The "Brief Operating Instructions Part 1: Sensor" are available via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App Detailed information about the device can be found in the Operating Instructions and the other documentation: • Internet: www.endress.com/deviceviewer •...
-
Page 4: Table Of Contents
Table of contents Flowmeter Proline 300 Table of contents About this document ............. . 5 Symbols . -
Page 5: About This Document
Flowmeter Proline 300 About this document About this document Symbols 1.1.1 Safety symbols DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in serious or fatal injury. - Page 6 About this document Flowmeter Proline 300 Symbol Meaning Potential equalization connection (PE: protective earth) Ground terminals that must be connected to ground prior to establishing any other connections. The ground terminals are located on the interior and exterior of the device: •...
-
Page 7: Safety Instructions
Flowmeter Proline 300 Safety instructions Safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣ Are authorized by the plant owner/operator. -
Page 8: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties. -
Page 9: Security
Flowmeter Proline 300 Safety instructions IT security Our warranty is valid only if the product is installed and used as described in the Operating Instructions. The product is equipped with security mechanisms to protect it against any inadvertent changes to the settings. -
Page 10: Product Description
Product description Flowmeter Proline 300 Product description The device consists of a Proline 300 transmitter and an electromagnetic Proline Promag sensor. The device is available as a compact version: The transmitter and sensor form a mechanical unit. N ic te r e r g ö... -
Page 11: Mounting
Flowmeter Proline 300 Mounting Mounting For detailed information about mounting the sensor, see the Sensor Brief Operating Instructions → 3 Turning the transmitter housing To provide easier access to the connection compartment or display module, the transmitter housing can be turned. - Page 12 Mounting Flowmeter Proline 300 4 mm 7 Nm (5.2 lbf ) A0043150 2 Ex housing Loosen the fixing screws. Turn the housing to the desired position. Tighten the securing screws. Endress+Hauser...
-
Page 13: Turning The Display Module
Flowmeter Proline 300 Mounting Turning the display module The display module can be turned to optimize display readability and operability. – – – 3 mm A0030035 Depending on the device version: Loosen the securing clamp of the connection compartment cover. -
Page 14: Electrical Connection
Electrical connection Flowmeter Proline 300 Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage. - Page 15 Flowmeter Proline 300 Electrical connection Signal cable Current output 4 to 20 mA HART A shielded cable is recommended. Observe grounding concept of the plant. Current output 0/4 to 20 mA Standard installation cable is sufficient Pulse /frequency /switch output...
- Page 16 Electrical connection Flowmeter Proline 300 Standard cable - customer-specific cable With the following order option, no cable is supplied with the device and must be provided by the customer: Order code for DKX001: Order code 040 for "Cable", option 1 "None, provided by customer, max 300 m"...
-
Page 17: Connecting The Measuring Device
Flowmeter Proline 300 Electrical connection 5.2.3 Terminal assignment Transmitter: supply voltage, input/outputs The terminal assignment of the inputs and outputs depends on the individual order version of the device. The device-specific terminal assignment is documented on an adhesive label in the terminal cover. - Page 18 Electrical connection Flowmeter Proline 300 5.3.1 Connecting the transmitter A0026781 Terminal connection for supply voltage Terminal connection for signal transmission, input/output Terminal connection for signal transmission, input/output or terminal connection for network connection via service interface (CDI-RJ45); optional: connection for external WLAN antenna or...
- Page 19 Flowmeter Proline 300 Electrical connection N ic N ic t e r t e r e r g ö f f e r g ö f f iz e iz e t e n t e n r ir r ir...
- Page 20 Electrical connection Flowmeter Proline 300 22 mm 24 mm – A0029816 10. Connect the cable according to the terminal assignment. Signal cable terminal assignment: The device-specific terminal assignment is documented on an adhesive label in the terminal cover. Supply voltage terminal assignment: Adhesive label in the terminal cover or →...
-
Page 21: Ensuring Potential Equalization
Flowmeter Proline 300 Electrical connection 5.3.2 Connecting the remote display and operating module DKX001 The remote display and operating module DKX001 is available as an optional extra. • The remote display and operating module DKX001 is only available for the following housing version: order code for "Housing": option A "Aluminum, coated"... - Page 22 • Grounding rings can be ordered separately as an accessory from Endress+Hauser . When ordering make sure that the grounding rings are compatible with the material used for the...
- Page 23 Flowmeter Proline 300 Electrical connection Potential equalization via grounding electrodes on process connection A0028972 Hexagonal-headed bolts of process connection Integrated grounding electrodes O-ring seal Sensor 5.4.2 Promag P CAUTION Insufficient or faulty potential equalization. May destroy the electrodes and thus result in the complete failure of the device! ‣...
- Page 24 Electrical connection Flowmeter Proline 300 Metal, grounded pipe A0016315 3 Potential equalization via measuring tube Unlined and ungrounded metal pipe This connection method also applies in situations where: • The customary potential equalization is not used • Equalizing currents are present...
- Page 25 Flowmeter Proline 300 Electrical connection A0029339 5 Potential equalization via ground terminal and ground disks (PE = P Connect the ground disks to the ground terminal via the ground cable. Connect the ground disks to ground potential. PE = P...
-
Page 26: Ensuring The Degree Of Protection
Electrical connection Flowmeter Proline 300 Ensuring the degree of protection The measuring device fulfills all the requirements for the degree of protection IP66/67, Type 4X enclosure. To guarantee the degree of protection IP66/67, Type 4X enclosure, carry out the following steps after the electrical connection: Check that the housing seals are clean and fitted correctly. -
Page 27: Operation Options
Flowmeter Proline 300 Operation options Operation options Overview of operation options A0034513 Local operation via display module Computer with Web browser (e.g. Internet Explorer) or with operating tool (e.g. FieldCare, DeviceCare, AMS Device Manager, SIMATIC PDM) Field Xpert SFX350 or SFX370... -
Page 28: Structure And Function Of The Operating Menu
Operation options Flowmeter Proline 300 Structure and function of the operating menu 6.2.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation task-oriented Setup Diagnostics Operating menu for experts Expert function-oriented A0014058-EN 6 Schematic structure of the operating menu 6.2.2... -
Page 29: Access To The Operating Menu Via The Local Display
Flowmeter Proline 300 Operation options Access to the operating menu via the local display X X X X X X 19.184 mA 12.5 X X X X X X Language à English 20.50 Deutsch Español Français Xxxxxxx A B C D E F G H I J K M N O P Q R S T U V W +0.000 Xx... - Page 30 Operation options Flowmeter Proline 300 6.3.1 Operational display Explanatory symbols for the measured value Status area • Depends on the device version, e.g.: The following symbols appear in the status area of the • : Volume flow operational display at the top right: •...
- Page 31 Flowmeter Proline 300 Operation options Numeric editor Confirms selection. Moves the input position one position to the left. Exits the input without applying the changes. Inserts decimal separator at the cursor position. Inserts minus sign at the cursor position. Clears all entered characters.
-
Page 32: Access To The Operating Menu Via The Operating Tool
System integration Flowmeter Proline 300 Keys and meaning Minus/Enter key combination (press the keys simultaneously) With an operational display: • If keypad lock is active: Pressing the key for 3 s deactivates the keypad lock. • If keypad lock is not active: Pressing the key for 3 s opens the context menu including the option for activating the keypad lock. -
Page 33: Setting The Operating Language
Flowmeter Proline 300 Commissioning • Checklist for "Post-mounting check" → 13 • Checklist for "Post-connection check" → 26 Setting the operating language Factory setting: English or ordered local language X X X X X X X 20.50 Main menu... -
Page 34: Protecting Settings From Unauthorized Access
Commissioning Flowmeter Proline 300 Example: Available submenus, wizards Meaning Status input Current output 1 to n Pulse/frequency/switch output 1 to n Relay output Double pulse output Display Configuration of the display format on the local display Low flow cut off... -
Page 35: Diagnostic Information
Flowmeter Proline 300 Diagnostic information Diagnostic information Faults detected by the self-monitoring system of the measuring device are displayed as a diagnostic message in alternation with the operational display. The message about remedial measures can be called up from the diagnostic message, and contains important information on the fault. - Page 36 *71574812* 71574812 www.addresses.endress.com...
