Electrical connection
5.1.3 Connecting cable for remote version
Connecting cable (standard)
Standard cable
Flame resistance
Oil-resistance
Shielding
Cable length
Operating temperature
1) UV radiation may cause damage to the outer jacket of the cable. Protect the cable from exposure to sun as much
as possible.
Connecting cable (reinforced)
Cable, reinforced
Flame resistance
Oil-resistance
Shielding
Strain relief and
reinforcement
Cable length
Operating temperature
1) UV radiation may cause damage to the outer jacket of the cable. Protect the cable from exposure to sun as much
as possible.
14
2 × 2 × 0.5 mm 2 (22 AWG) PVC cable with common shield (2 pairs, pair-stranded)
According to DIN EN 60332-1-2
According to DIN EN 60811-2-1
Galvanized copper-braid, opt. density approx.85 %
5 m (16 ft), 10 m (32 ft), 20 m (65 ft), 30 m (98 ft)
When mounted in a fixed position: –50 to +105 °C (–58 to +221 °F); when cable can
move freely: –25 to +105 °C (–13 to +221 °F)
2
2 × 2 × 0.34 mm (22 AWG) PVC cable with common shield (2 pairs, pair-stranded)
and additional steel-wire braided sheath
According to DIN EN 60332-1-2
According to DIN EN 60811-2-1
Galvanized copper-braid, opt. density approx. 85%
Steel-wire braid, galvanized
5 m (16 ft), 10 m (32 ft), 20 m (65 ft), 30 m (98 ft)
When mounted in a fixed position: –50 to +105 °C (–58 to +221 °F); when cable can
move freely: –25 to +105 °C (–13 to +221 °F)
