Commissioning
The desired units can be selected in the System units submenu. The wizards systematically
guide the user through all the parameters required for configuration, such as parameters for
measurement or outputs.
The wizards available in the particular device can vary on account of the device version
(e.g. sensor).
Wizard
System units
Medium selection
Pulse/frequency/switch output
Analog inputs
Display
Low flow cut off
Advanced setup
8.5

Defining the tag name

To enable fast identification of the measuring point within the system, you can enter a unique
designation using the Device tag parameter and thus change the factory setting.
 10 Header of the operational display with tag name
1 Tag name
Navigation
"Setup" menu → Device tag
36
Meaning
Configure the units for all measured variables
Define the medium
Configure the selected output type
Configure the analog inputs
Configure the measured value display
Set the low flow cut off
Additional parameters for configuration:
• Medium properties
• External compensation
• Sensor adjustment
• Totalizer 1 to n
• Heartbeat
• Configuration backup display
• Administration
1 XXXXXXXXX
Flowmeter Proline 200
A0029422
